Stereo Zoom Microscope Xts20+3631a
BEIJING TECH INSTRUMENT CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Stereo Zoom Microscope Xts20+3631a
BEIJING TECH INSTRUMENT CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: metal
- Color: White, Black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: metal
- Color: White, Black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | metal |
|---|---|
| Color | White, Black |
Product details
| Materials | metal |
|---|---|
| Color | White, Black |
From the supplier
XTS20+3622A Trinocular microscope with Flexible Arm Stand
It provides excellent 3D images with high resolution. Once brought in focus, images remains clear throughout whole zoom range, it has large field of view, long working distance, and big depth of field, a wide variety of optical lenses and stands are available.
● Binocular Viewing Head, Inclined 45 degree, can be rotated a full 360°
● Zoom Range: 0.7x-4.5x
● Zoom Ratio: 6.5:1
● Eyepiece: WF10X /23 high eyepiece point eyepiece (standard)
● Magnification: 7x-45x (with accessory lens: 2.1x-225X)
● Working distance: 108mm. It can be 38-314mm with optional Auxiliary Lens.
● Field of view: 31.5mm- 4.9mm
● Interpupillary distance: 55mm-75mm
● Diopter correction: ±5 degree
● Flexible arm Clamp & Pole stand
Flexible Arm: Up to down of working vertical travel distance 265mm, can be moved 745mm of range in any position from the 5/8inch fitting to mount centerline.
Vertical Post: OD. 31.5mm, main post 390mm.
A Lock Ring on vertical post for stopping.
Clamp max.: opening 57mm
From the supplier
XTS20+3622A Trinocular microscope with Flexible Arm Stand
It provides excellent 3D images with high resolution. Once brought in focus, images remains clear throughout whole zoom range, it has large field of view, long working distance, and big depth of field, a wide variety of optical lenses and stands are available.
● Binocular Viewing Head, Inclined 45 degree, can be rotated a full 360°
● Zoom Range: 0.7x-4.5x
● Zoom Ratio: 6.5:1
● Eyepiece: WF10X /23 high eyepiece point eyepiece (standard)
● Magnification: 7x-45x (with accessory lens: 2.1x-225X)
● Working distance: 108mm. It can be 38-314mm with optional Auxiliary Lens.
● Field of view: 31.5mm- 4.9mm
● Interpupillary distance: 55mm-75mm
● Diopter correction: ±5 degree
● Flexible arm Clamp & Pole stand
Flexible Arm: Up to down of working vertical travel distance 265mm, can be moved 745mm of range in any position from the 5/8inch fitting to mount centerline.
Vertical Post: OD. 31.5mm, main post 390mm.
A Lock Ring on vertical post for stopping.
Clamp max.: opening 57mm
About the supplier
Main products: Microscopes
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Manufacturer
- ✓Founded 1971
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 1971
