Steel Metal Band Saw Machine
Changge Kowloon Machinery Manufacturing Co.,Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Steel Metal Band Saw Machine
Changge Kowloon Machinery Manufacturing Co.,LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Size: 230*150*180cm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Henan, China
About this product
- Size: 230*150*180cm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Henan, China
Product details
| Size | 230*150*180cm |
|---|---|
| Color | Gray |
Product details
| Size | 230*150*180cm |
|---|---|
| Color | Gray |
From the supplier
The steel bar winding machine is mainly composed of the trolley part
(including the steel bar receiving disc, the line of defense modulator, and the track),
the power cabinet (numerical control memory operation parameters),
and the transmission structure (motor, winding cage support).
It is mainly suitable for bending processing of main skeleton steel bars in large-scale engineering concrete
structures such as high-rise buildings, highways, high-speed railways, and large-scale bridges.
Model
KW- 3000
Rebar cage diameter
600-3000MM
Reinforcement cage length
12-30m
Trolley walking motor
3KW
Roller motor
7.5KW
Reinforcement motor
7.5KW
Winding speed
0-15.4m/min
Trolley speed
0-1.38m/min
Host size
200*100*80cm
Trolley size
230*150*180cm
Product Advantages:
Product advantages:
Adopts CNC technology, uniform speed and spacing of reinforcement wrapping, guarantees stable quality even with long-term operation, fast and efficient
Using numerical control technology, the speed and spacing of the winding ribs are uniform, and the quality
is stable even after long-term operation, and it is fast and efficient.
Modular Design, Quick Component Disassembly, Easy Relocation and Transport
With modular design, each component can be quickly disassembled, moved, and transported conveniently and quickly.
CanWindSteel Cage with Adjustable Diameter, Customizable Length, Meets Various Rebar and Stirrup Quantity, Model, Size, Length Requirements
The diameter of the rebar cage can be adjusted, and the length can be customized to meet various requirements
for the number, model, size, and length of the main reinforcement stirrup
Simple Operation, Workers Need Only Simple Training, 2-3 Person Team Can Complete Overall Equipment Operation
The operation is simple. Workers can control the operation with simple training, saving labor. A group of 2 to
3 people can complete the overall operation of the equipment.
Electric Control Box, Remote Dual Control, Flexible and Convenient Operation
The electric control box and the remote control have dual control functions, making the control operation more flexible and convenient.
Host Has Memory Function, Can Adjust Storage Job Parameters at Any Time
The host has a memory function, which can adjust and store operating parameters at any time.
Rebar Tightening Without Overlap, Saves 1.5% Material Compared to Manual Work, Reduces Construction Cost
Stirrup tightening does not require overlapping, which saves materials by 1.5% compared with manual work, and reduces construction costs.
Company Information Exhibition Customer Photos Why Choose Us
1. Under the premise of quality assurance, the price is more favorable 2.16 years of professional construction steel equipment manufacturer 3. The professional R & D team will launch new models every month to adapt to the customer market and have the ability to customize 4. Complete production line for each part 5. Perfect export inspection line to ensure the quality of each unit. 6. The ultimate after-sales service, ready to reply to you one-on-one at any time, providing lifetime after-sales service 7. For dealer customers, cooperate with customers to launch new product plans, help customers promote marketing and sales, mutual benefit and win-win is our ultimate Certifications
