Horizontal dough mixer is used for dough making. After kneading, calendering and folding in the mixing process, the dough surface is smooth, with good elasticity, toughness and extensibility. Suitable for tough biscuits and crisp biscuits

Machine configuration:

1. Mixing capacity: 250 kg dough / time;

2. Paddle form: horizontal single paddle, S-shaped; /

3. Mixing barrel type: oblique U-shaped, push-pull barrel lid;

4. Working speed: 43r / min; / Distribution power: 11.37KW; /

5. Pouring method: electric; /

6. The carbon steel material is used for the mixing barrel, mixing shaft and mixing pulp;

7. The outer cover is made of stainless steel, and the side plate uses Q235 carbon steel material;

8. Ziguang brand for motor and reducer

9. Install safety protection devices such as emergency stop switch and limit switch;

10. Use domestic brands to control electrical appliances

11. The bearings use the UBC brand;

Product Features:

After putting the kneaded flour and other ingredients into the machine, the agglomerates are formed into unripe biscuits, which will be finally placed in the oven

Roll the mold once.

1. Mold roll material: 45 high quality carbon steel and copper, roll length is 640 mm

2. After the rubber roller is straight: non-toxic oil-resistant material is adopted, and the hardness is A60;

3. Working width: 600mm, external dimensions: according to design, weight: 2.5 (T), power distribution: 8.2kw

It is used to transport the formed biscuits to the oven, and has the functions of recovering sugar, salt, sesame and other residual materials and eliminating waste cake blanks that are not well formed from the production line

Machine configuration:

1. The two front and back conveyor belts are convenient for the recovery of salt and sugar residues;

2. Working width: 600mm;

3. Dimensions: 1600X1730X1125, weight: 1.8 (T), power distribution: 1.5KW;

4. A waste cake cylinder dropping device is provided;

5. Q235 carbon steel material is used for the side plate and frame plate; stainless steel is used for the pallet;

6. Conveyor belt rubber roller adopts food grade non-toxic oil-resistant material rubber;

7. The conveyor belt uses a circular sail belt; the conveyor belt adopts pneumatic tension and pneumatic deviation adjustment, and the cylinder uses the Yadeke brand;

8. Ziguang brand for motor and reducer, frequency conversion speed regulation;

9. Install safety protection devices such as emergency stop switches;

10. Use domestic brands to control electrical appliances;

11. Bearings use UBC brand, TR bearing with bearing;
