About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
From the supplier
Equipped with reliable Cummins QSM11-C360 engine
Single-handle electro-hydraulic control power shift T/M, 6 forward gears and 3 reverse gears, making operation simple and convenient
Hydraulic locking, automatic locking/unlocking NO-SPIN differential ensures stability and strong traction
Ideal axle load distribution provides excellent stability when cutting hard roads
Highly efficient, maintainable hydraulic system allows every component to be fully utilized
Box frames and advanced T/M allow it to perform heavy tasks
Flexible blade suspension system and articulated frame allow for wide working range
Overall Dimension complete machine size
1
Length Total length12500mm
2
Width Total width3300mm
3
Height(To the top of the cab) Total height (to the top of the cab)3700mm
4
Wheel base7760mm
5
Tread track2650mm
6
Min. turning radius minimum turning radius9000mm
Main Technical Specification Main technical parameters
1
Operating weight28000kg
2
Blade length Blade length4920mm
3
Blade height695mm
4
Blade width Blade thickness25mm
5
Max.& nbsp;Lift above ground Maximum lifting height515mm
6
Max.& nbsp;grading depth Maximum cutting depth735mm
7
Max.& nbsp;shoulder reach outside rear tire blade maximum lateral reach distance2260mm（L）/1950mm（R）
8
Traveling speed(Km/h), 6 forward and 3 reverse driving speed, six first and three last(1)forward
5.4/8.2/12.7/19.3/27.5/41 km/h
(2)reverse
5.4/12.7/27.5 km/h
Diesel engine engine
1
ModelCummins QSM11-C360
Cummins QSM11-C360 Engine
2
TypeEFI,turbocharger,air-to-aircooling,temperature control independent cooling system
EFI, turbocharged, air-to-air intercooling; temperature-controlled independent cooling system
3
Rated output Rated power268(kW)
4
Rated speed2100(r/min)
5
Max. Torque Maximum torque1830(N.m)/(1400r/min)
From the supplier
Equipped with reliable Cummins QSM11-C360 engine
Single-handle electro-hydraulic control power shift T/M, 6 forward gears and 3 reverse gears, making operation simple and convenient
Hydraulic locking, automatic locking/unlocking NO-SPIN differential ensures stability and strong traction
Ideal axle load distribution provides excellent stability when cutting hard roads
Highly efficient, maintainable hydraulic system allows every component to be fully utilized
Box frames and advanced T/M allow it to perform heavy tasks
Flexible blade suspension system and articulated frame allow for wide working range
Overall Dimension complete machine size
1
Length Total length12500mm
2
Width Total width3300mm
3
Height(To the top of the cab) Total height (to the top of the cab)3700mm
4
Wheel base7760mm
5
Tread track2650mm
6
Min. turning radius minimum turning radius9000mm
Main Technical Specification Main technical parameters
1
Operating weight28000kg
2
Blade length Blade length4920mm
3
Blade height695mm
4
Blade width Blade thickness25mm
5
Max.& nbsp;Lift above ground Maximum lifting height515mm
6
Max.& nbsp;grading depth Maximum cutting depth735mm
7
Max.& nbsp;shoulder reach outside rear tire blade maximum lateral reach distance2260mm（L）/1950mm（R）
8
Traveling speed(Km/h), 6 forward and 3 reverse driving speed, six first and three last(1)forward
5.4/8.2/12.7/19.3/27.5/41 km/h
(2)reverse
5.4/12.7/27.5 km/h
Diesel engine engine
1
ModelCummins QSM11-C360
Cummins QSM11-C360 Engine
2
TypeEFI,turbocharger,air-to-aircooling,temperature control independent cooling system
EFI, turbocharged, air-to-air intercooling; temperature-controlled independent cooling system
3
Rated output Rated power268(kW)
4
Rated speed2100(r/min)
5
Max. Torque Maximum torque1830(N.m)/(1400r/min)
