About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
From the supplier
Equipped with Cummins 6CTA8.3-C240 engine
Single-handle electro-hydraulic control power shift T/M, 6 forward gears and 3 reverse gears, making operation simple and convenient
Hydraulic locking, automatic locking/unlocking NO-SPIN differential ensures stability and strong traction
Ideal axle load distribution provides excellent stability when cutting hard roads
Highly efficient, maintainable hydraulic system allows every component to be fully utilized
Box frames and advanced T/M allow it to perform heavy tasks
Flexible blade suspension system and articulated frame allow for wide working range
Overall Dimension complete machine size
1
Length Total length9980mm
2
Width Total width3100mm
3
Height(To the top of the cab) Total height (to the top of the cab)3630mm
4
Wheel base6900mm
5
Tread track2580(mm)
Main Technical Specification Main technical parameters
1
Operating weight20000kg
2
Blade length Blade length4420mm
3
Blade height580mm
4
Shovel Blade thickness16mm
5
Traveling speed(Km/h), 6 forward and 3 reverse driving speed, six first and three last(1)forward
4.96/8.55/11.3/19.32/24.25/40
(2)reverse
4.96/11.3/23
Diesel engine engine
1
ModelCummins6CTA8.3-C240
2
TypeDirect injection. Turbocharged. Water cooling
Direct injection, pressurized, water cooling
3
Rated output Rated power179 kW
4
Rated speed2200(r/min)
5
Max. Torque Maximum torque1028(N.m)/(1500r/min)
From the supplier
Equipped with Cummins 6CTA8.3-C240 engine
Single-handle electro-hydraulic control power shift T/M, 6 forward gears and 3 reverse gears, making operation simple and convenient
Hydraulic locking, automatic locking/unlocking NO-SPIN differential ensures stability and strong traction
Ideal axle load distribution provides excellent stability when cutting hard roads
Highly efficient, maintainable hydraulic system allows every component to be fully utilized
Box frames and advanced T/M allow it to perform heavy tasks
Flexible blade suspension system and articulated frame allow for wide working range
Overall Dimension complete machine size
1
Length Total length9980mm
2
Width Total width3100mm
3
Height(To the top of the cab) Total height (to the top of the cab)3630mm
4
Wheel base6900mm
5
Tread track2580(mm)
Main Technical Specification Main technical parameters
1
Operating weight20000kg
2
Blade length Blade length4420mm
3
Blade height580mm
4
Shovel Blade thickness16mm
5
Traveling speed(Km/h), 6 forward and 3 reverse driving speed, six first and three last(1)forward
4.96/8.55/11.3/19.32/24.25/40
(2)reverse
4.96/11.3/23
Diesel engine engine
1
ModelCummins6CTA8.3-C240
2
TypeDirect injection. Turbocharged. Water cooling
Direct injection, pressurized, water cooling
3
Rated output Rated power179 kW
4
Rated speed2200(r/min)
5
Max. Torque Maximum torque1028(N.m)/(1500r/min)
