About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
From the supplier
Cummins high-power engine (in compliance with second-stage emission regulations) is powerful, efficient, energy-saving, reliable and durable; advanced negative flow hydraulic system is comfortable to operate, high operating efficiency, and excellent cost performance; full power control, four power modes adapt to different working conditions; reliable and accurate fuel injection system, which controls fuel injection volume in real time, making combustion more complete and fuel efficiency higher; full three-dimensional modeling and finite element analysis technology ensure the reliability and stability of structural components.
Operating weight
Kg
34000
Rated powerKW/rpm
241/2000
Rated bucket capacitym3
1.7
Overall lengthmm
10820
Overall width (600mm track) Overall width (600mm track)mm
3280
Overall heightmm
3546
Turntable width Platform widthmm
3060
Maximum traction Max.& nbsp;tractionKN
283
Traveling speed (H/L)Km/hr
4.8/3.0
Swing speedrpm
10.0
GradeabilityDegree(%)
35（70%）
Ground pressureKgf/cm2
0.631
Maximum mining radius10233 mm
Ground maximum digging radius10028 mm
Maximum mining depth6536 mm
Ground maximum digging depth6331 mm
Maximum vertical digging depth4758 mm
Maximum digging height9617 mm
Maximum unloading height6666 mm
Minimum front radius of gyration Min. front turning radius4256 mm
Bucket digging force225 KN
Stick digging force182 KN
From the supplier
Cummins high-power engine (in compliance with second-stage emission regulations) is powerful, efficient, energy-saving, reliable and durable; advanced negative flow hydraulic system is comfortable to operate, high operating efficiency, and excellent cost performance; full power control, four power modes adapt to different working conditions; reliable and accurate fuel injection system, which controls fuel injection volume in real time, making combustion more complete and fuel efficiency higher; full three-dimensional modeling and finite element analysis technology ensure the reliability and stability of structural components.
Operating weight
Kg
34000
Rated powerKW/rpm
241/2000
Rated bucket capacitym3
1.7
Overall lengthmm
10820
Overall width (600mm track) Overall width (600mm track)mm
3280
Overall heightmm
3546
Turntable width Platform widthmm
3060
Maximum traction Max.& nbsp;tractionKN
283
Traveling speed (H/L)Km/hr
4.8/3.0
Swing speedrpm
10.0
GradeabilityDegree(%)
35（70%）
Ground pressureKgf/cm2
0.631
Maximum mining radius10233 mm
Ground maximum digging radius10028 mm
Maximum mining depth6536 mm
Ground maximum digging depth6331 mm
Maximum vertical digging depth4758 mm
Maximum digging height9617 mm
Maximum unloading height6666 mm
Minimum front radius of gyration Min. front turning radius4256 mm
Bucket digging force225 KN
Stick digging force182 KN
