Golden Bake group was established in the year 1999 with a vision to be the most completely automatic biscuit machine system supplier in this field. Pursuing innovative technology is our goal; meeting customized requirement is our mission; guaranteeing excellent after-sale service is our aim.

Providing customers with a whole automatic biscuit production line machinery from feeding to packing. With our cooperative enterprise STM, HP, TFM and EMC, we unite the highest quality standards and innovation in the Golden Bake Group.

Our cooperative enterprises:

• Smart-Tech Machinery Manufacturing Co.,Ltd specializes in automatic material conveying systems for foods and cooling conveyor equipment for biscuits
• Huapu Food Machinery Manufacturing Co.,Ltdis Chinese market leader in biscuit forming and baking manufacturer for hollow panda biscuits, potato crisp crackers, soda biscuits, cookies, egg tart biscuit and wafer stick.
• Zhuhai Tianxiang Food Machinery Co.,Ltd focus on equipment for biscuit sandwiching. It has become the first choice of the major sandwich biscuit-making factories in China. Such as JIASHILI,DALI and so on.

Apart from the integrated system hardware service, the services Golden Bake offers include all stages: from plant design, machine construction, manufacture, and assembly up to the smooth commissioning phase at your site. Our comprehensive after-sales service program is available throughout our lines’ entire life cycle.

Please feel free to contact us if you need any further information. We will offer you customized solutions for your demands.

Product Description

Silo system/ Dosing system

Our automatic silo system is suitable for small and medium-sized food biscuit production factories. Adopting efficient, durable negative pressure conveying and dust-free techniques handling way aims to ensure the workshop is dust-free, clean and hygienic, reduce labor intensity and labor, and promote work efficiency but a low investment. Can be used directly in the original biscuit production line without changing the original equipment. Or start a new item. This machine can dose loose-packed powder, such as flour and sugar powder. Also can dosing liquid and semi-liquid, such as palm oil, shortening and water. Adopting a pneumatic conveying system for transport powder in the sealed pipe. Due to the weight measurement method, the error is less than 1kg. No dead angle in the pipe without using a screw conveyor. Adopting with pump conveying system for transport liquid in a sealed pipe. Due to the weight measurement method, the error is less than 1kg. To avoid the error caused by the difference in material density and temperature in different batches, we don't use flow measurement.
The flour dosing system consists of a bag dump station, flour screener, flour silo, magnetic separation machine and weight hopper.
The sugar powder dosing system consists of an online milling system(the amount of grinding depends on use). Avoiding caking and blocking in tubes, we don't store sugar powder. We only use artificial pour sugar or storage sugar granule.
Shortening and palm oil dosing system equipped with whole process insulation function. According to the different melting points of shortening and palm oil, our system can keep the material in a liquid state suitable for pipeline transportation under the lowest power consumption insulation temperature.

NO

Item

Description

1

Flour cache system

Adopt efficient, durable negative pressure conveying and feeding way with dust-free techniques handling, to ensure workshop dust-free,clean and hygienic, reduce labour intensity and human numbers,and improve work efficiency

2

Flour/sugar powder weighing system

Flour weighing system adopted with high efficiency and durable negative pressure transportation and dust-free treatment technology for powder delivery, and accurate measurement to ensure that the workshop is dust-free, and hygienic. This system can reduce labor and labor intensity and improve work efficiency.

3

Sugar quantitative / pulverization / weighing/ feeding system

To provide a dust-free, hygienic and clean workshop, reduce labor intensity and labor; improve working efficiency. This system Adopts a specially designed white sugar milling structure. Fast milling speed, low temperature of powdered sugar, high-efficiency and durable negative pressure conveyor, powder feeding method of dust-free treatment technology and precise measurement method.

4

Palm oil Quantitative weighing system

Adopt Weighing module metering, guarantee metering is accurate,labor-saving , improves high efficiency.

5

Water Quantitative weighing system

6

Shortening quantitative system (for cream mixer)

7

Sugar quantitative pulverization feeding system

8

Automatic PLC control electric engineering

Our Services

To solve the demand of customer is our goal. To meet the customized requirements is our mission, to innovate technologies is our moving direction.

We not only provide advance equipment, but also provide the optimized solution for the whole project, from planning design to equipment installation and commissioning. Since the company incorporated, our machinery are good sell to overseas, customers cover more than 20 countries. Because of the high-quality machinery and excellent service, Golden Bake win the great recognition and reputation from customer.

Welcome to contact with us!
