Product advantages:
Modular design, lifting capacity of 1.0t-80t, working level M4-M6; M4-M6; the whole machine has compact structure, low clearance design, reduced equipment height and reduced dead weight;; operation and lifting full-mechanism frequency conversion control; The gear material of the gearbox is chromium-molybdenum alloy, and the aluminum alloy die-cast shell has light dead weight; the heavy-duty electromagnetic disc brake has stable braking, and the brake pad life is routinely braked 1 million times; it adopts a T-level forged hook, which is optimized in size and easy to maintain; Newly designed 100Hz high-efficiency variable frequency motor; large diameter drum, long service life of wire rope; load limit sensor is set at the fixed end of wire rope, sensitive trigger, light load weighing accuracy is ±5%, heavy load weighing accuracy is ±2%; Aviation plug, easy to install; standard clearance or low clearance hoist can be provided, and a lifting mechanism for integral double beam trolleys or double beam trolleys can be provided; Including anti-swing control, micro-motion/inching function, abnormal torque protection, wire rope protection, brake failure protection and other functions.
