Type Type Detail Details Description Description External Dimensions Product Dimension 138：138：153mm Color colour Yellow, White, Customizable Colors Edition Package Dimensions Packing measurement 172:225:173mm Product Gross Weight 1..0KG Product Net Weight 0.67KG Packing Box 370:540:465mm Case Weight 14KG PCS 12 Total Power Consumption Power 48WPositive/Negative5W Type Type Detail Details Description Description Projection Parameters
Display Parameter Display Technology Display Technical LCD Projection Light Source Light Source LED Color Temperature Color temperature 6500k Light Source Life 30000H Brightness Light Luminance 150ANSI Positive/Negative10% Lamp Type Light Type LED Throw Ratio Contrast 0.65 ：1 Physical Resolution Standard Resolution 1280*720/60HZ Supported Resolution 1080*1920/60HZ Contrast Ratio 1200：1 Projection Size Projection Area Picture Scale 4：3/ 16:9 Optimum Size 35-200 UniformityLuminance Uniformity 72% Effective Projection Distance Projection Distance 1-4.5M Focus Mode Focus mode Auto Focus Keystone Correction Keystone Correction Automatic Trapezoid Correction (Vertical) Projection Mode Projection Mode Ceiling/Front Projection/Rear Projection
Hoisting/Front/ Rear Project Speaker Speaker Built-inBOXSpeaker 4Ω5W*1
Built-in Box Speaker 4Ω5W*1 Interface Configuration Connector Details USBConnector
USB Port USBConnector
USB Port Standard USB2.0×1
Standard USB2.0×2 HDMIConnector
HDMI Port HDMIConnector
HDMI Port StandardHDMI×1
Standard HDMI×1 Audio Output Interface
Audio Output Port φ3.5Audio Interface
φ3.5 Audio Port Standard3.5Audio Interface×1
Standard φ3.5 Audio Port ×1 Power Interface
Power Jack TYPE-C Connector
Type-c Port 100~250V 50/60HZ Button
Power Button Power Button
Turn on/ off Button 1Power Button
Power Key ×1 Standard Accessories Standard Accessories Adapter TYPE-C Connector
Type-c Port SupportPD1.2M AC Cable ×1
Support PD protocol 1.2M AC Cable ×1 HDMIThread HDMI Cable Standard Configuration Standard HDMI Cable Length1M ×1
1M HDMI Cable×1 Software Configuration Software Details Type Type Detail Details Description Description Operating System
Operation System CPU Control AmlogicT950s • Quad-CoreCortex-A53 GPU • ARM Mali-450 MP2 • SupportOpenGL ES 2.0 • Embedded High Performance2DHardware Acceleration Display • eDp/HDMI2.0/MIPI/LVDS/EBC Multimedia • Support4K 30fpsH.265/VP9Video Decoding;1080P60fpsH.265/H.264/VP9Video Decoding • H.265 video encoder 4K@30fps • Support8M ISP • Support1TComputing Power System Version Android 13 Configuration: Memory/Storage 1+8 WiFiNetwork Support 802.11 /b/g/n+BT5.0 Wifi6
2.4G+5G Dual WiFi Modes Remote Control Domestic Version: Infrared+Bluetooth+Voice
Overseas Version: Infrared+Bluetooth
