PT-L200A LEDHandheld stroboscopeThe interior adopts a high-performance microcomputer processing unit, and efficient program processing method realizes high-precision strobe; the LCD screen is used to display data, making human-computer interaction more convenient and intuitive; the high-efficiency energy conversion chip is used to make the energy output more stable and reliable; imported LED lamp beads are characterized by environmental protection, long life, high brightness, and low heat of the whole machine; built-in high-performance battery makes the product more suitable for long-term uninterrupted use; Array LED lamp beads are arranged for high and uniform brightness.

technical parameters

1. Power supply: DC12.6V 2900mAh;

2. Display: LCD LCD display;

3. Strobe accuracy: ±0.01%;

4. Trigger frequency range: 50-36,000 times/minute;

5. Scroll function: In external trigger mode, you can move the screen forward or backward at a certain speed;

6. Triggering methods: five working modes: internal trigger, single pulse, perimeter standard length, encoder, and gear;

7. Strobe unit adjustable: switching between times per minute (rpm) and times per second (Hz) can be realized;

8. Brightness adjustment: The brightness can be adjusted within a certain range, ranging from 8us to 100us;

9. External trigger sensor types: photoelectric switch, Hall switch, proximity switch, encoder, gear sensor signal;

10. External trigger signal requirements: low level 0~0.7V, high level 2.7V (allowed 24V), rising edge trigger, high level duration 20us;

11. External trigger sensor power supply: DC12V 50mA (provided by strobe);

12. Overall size (length × width × height): 203mm(L)×80mm(W)×85mm(H).

product features

1. Using imported encoders and streamlined operating software, knob adjustment is faster, accurate and practical, making it convenient, free and handy to use;

2. Built-in memory, with automatic memory function of flash frequency and internal parameters, providing convenience for next use;

3. The software has an externally triggered scrolling function to realize the entire screen observation of the pattern;

4. Multiple trigger modes: internal trigger and external trigger. The external trigger mode can achieve automatic tracking effect;

5. When the external trigger working mode is used, a photoelectric sensor, Hall switch, encoder or gear signal can be connected to realize the automatic tracking function of the pattern;

6. Frequency units Hz and f/m can be selected, and the software has brightness adjustment function, suitable for different use occasions;

7. Adopt imported high-power LEDs and built-in high-performance power supply modules to improve flash brightness and irradiation distance;

8. The software has four tracking programs, which can automatically track printing surfaces without fixed color scales;

9. High luminous efficiency and more uniform light.

The stroboscope is also called a stroboscope still image instrument or tachometer, stroboscope lamp, etc. The stroboscope itself can emit a short and frequent flash. When the flashing frequency of the stroboscope is adjusted so that it is close to (or synchronized with) the rotating (or motion) speed of the object to be measured, although the object to be measured is moving rapidly, it appears to be moving slowly or relatively still. By using this kind of vision persistence phenomenon, the human eye can easily observe the surface quality and operating conditions of the fast-moving object, and the flash frequency of the stroboscope is the rotating speed or motion frequency of the object to be detected (such as a motor). You can also use a stroboscope to analyze the vibration of objects, observe the movements of fast-moving objects, and take quick photos. It is suitable for printing, paper, textile, steel cold rolling, large generators, aluminum foil, machinery manufacturing and other industries.
