UTBOARD ENGINE-T2.5BMS



Specification list



Length:                   603（23.7）mm(in.)

Width:                    240（9.4） mm(in.)

Height:                   916（36.1）mm(in.)

Transom height:           417（16.4）mm(in.)

Net Weight:               9.8 kgs

Full throttle operating range: 4300~5500 r/min

Maximum output:          1.7（2.5）@4500 KW(HP)@r/min

Idling speed:              1100~1200 r/min

Engine type:              2-Stroke

Displacement:            58.0 cm3

Bore×Stroke:             44.0×38.0(1.65×1.42) mm(in.)

Control system:          Tiller

Starting System:          Manual

Gear positions:           Forward

Gear ratio:               2.08(27/13)

Trim and tilt system:       Manual tilt

Fuel tank volume:         1.1 L

Engine fuel ratio:         gasoline：engine oil=50：1

Gear oil:                0.045 L

Propeller spec:          3-7 1/4\"×6\" in

"}
