WC67K NC Press Brake Machine With E300
● Using CAN bus technology; servo control X, Y axis
● Built-in PLC; with machine tool motion control function
● Can according to the actual valve group timing free match
● Adjustable return distance
● Self-diagnosis and real-time alarm
● Reservation security interface

WC67K NC Press Brake Machine has segmented upper punch adopted oblique steel solid deflection compensation device, multi-V die, removement foot-pedal switch, and emergency stop button. It's back gauge and upper ram travel can automatically control, can micro-adjustment by manual and digital displayer.

Control axes: Upper ram(Y-axis), Back gauge (X-axis).
Capabilities: 40T/2200 - 600T/6000Main Feature

● Whole steel welded structure, with internal stress eliminated by vibration aging technology, high strength and good rigidity;
Torsion bar with hydraulics;
● Integrated hydraulic system, upper transmission, pressure control for adjustment of tonnage;
● Removement foot-pedal switch and emergency stop button;
● Segmented upper punch, multi-V die;
● Back gauge and upper ram travel automatic control, micro adjustment by manual and digital displayer;
● Oblique steel solid deflection compensation device is adopted for upper punch;
● International standard electrics and switches;
● Can equip kinds of NC controllers: Estun E21/E200P/E300, Delem DA41, Maper HT072, Elgo P40 ect;
● Control axes: Upper ram(Y-axis), Back gauge (X-axis).

Standard Components

● Estun E300 control
● Siemens motor
● German BOSCH-REXROTH hydraulic system
● USA Sunny oil pump
● EMB pipe connector
● HIWIN ball screw & guide rail (backgauge)
● Schneider electrics
● Fast clamp
● Servo motor and driver
● Y, X axis
● Multi-V dies
● Foot pedal with emergency stop button
● Side and back safety gates

Optional

●  Front light curtain
● Rear light curtain
● Front laser protection
● Movable support arm with linear guide
●  Air cooling system

Controller Function

Support x, y, R axis servo control,

C axis hydraulic compensation / mechanical compensation

Integral product structure, built-in high-performance A8 processor

Angle programming calculation function

Built in mold library and materials

R-axis collision avoidance and positioning function

5.6 inch, 640 × 480 dot matrix, 18 full color display screen

integrated IO ports, serial ports and USB port.

One key backup/restore of parameters

Mm/inch

Chinese/English

Torque Synchronous

Robust and strong steel welded structure with stress relieving

Stable and reliable hydraulic top driven

Torsion bar keeps the parallelism between two cylinders

Main Motor

German famous brand Siemens motor improves the life span of the press brake machine

and keeps the machine working in low noise environment.

Electrical System

Schneider electrical components make the NC hydraulic press brake machine performing well even the electricity is not

stable and customers can easily get the replacement anywhere in the world.

Servo motor and servo drive

Faster speed and higher accuracy to performance X & Y axes well.

Oil Pump

USA Sunny:
Amazing low noise, made of high strength cast iron and unique design for inner noise reduction
Low sensitivity to oil pollution and assure of long service life

Hydraulic System

Using Germany Bosch Rexroth valve make it more reliable and easy for maintenance.
Low sensitivity to oil pollution and assure of long service life

Punch & Die

standard top punch and multi-V bottom die for the use in various purposes. More press brake toolings can be selected as per your practical use.
The dies are made by 42CrMo steel, hardness after heat treatment up to 42 degrees, ensure the die service lifetime.

Backgauge

Backgauge system with Hiwin ball screw and slick rod for high precision.
High precision backgauge device, Taiwan Hiwin ball screw and linear guide rail.
Backgauge adopts horizontal shell installation structure with high reliability,

and single-shell double linear guide rails with high precision X-axis drive

Adjustable stoppers

Stop fingers can be adjusted up and down due to your workpiece requirements

Technical ParametersModelNormal ForceBending LengthPoles DistanceThroat
DepthStrokeMax. OpeningMain PowerWeightDimension (KN)(mm)(mm)(mm)(mm)(mm)(KW)(KG)LxWxH(mm)40T2200400220018502201003205.527502200x1200x191040T2500400250018502201003205.530002500x1200x191050T2200500220018502201003205.529502200x1200x191050T2500500250018502201003205.534002500x1200x200063T2500630250019002601203205.540002500x1300x221063T3200630320025602601203205.548003200x1300x221080T2500800250019903201203207.557002500x1400x230080T3200800320025603201203507.560203200x1500x230080T4000800400030003201203507.570004000x1500x2400100T25001000250020203201504007.560002500x1600x2400100T32001000320026003201504007.568003200x1600x2600100T40001000400030003201504007.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.5190003200x2000x3200250T400025004000300040025053018.5202004000x2000x3400250T500025005000400040025053018.5235005000x2000x3450250T600025006000500040025053018.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 Advantage
