About this product
- Materials: ABS
- Size: 480*335*460mm
- Color: bule
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Guangdong, China
About this product
- Materials: ABS
- Size: 480*335*460mm
- Color: bule
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Guangdong, China
Product details
| Materials | ABS |
|---|---|
| Size | 480*335*460mm |
| Color | bule |
Product details
| Materials | ABS |
|---|---|
| Size | 480*335*460mm |
| Color | bule |
From the supplier
★This multifunctional multimeter with high precision and high performance can measure AC/DC voltage, current, resistance, capacitance, frequency, duty ratio. It also can test NCV(non-contact voltage), live line, diode, transistor and continuity.
★Includes new generation, 15-function, auto-ranging automotive diagnostic multimeter.
★Digital display gives accurate indication of component outputs.
★Large easy to read high contrast display with bright, white backlight.
★Workshop-tough, durable bi-composite case with integral stand and auto power shut-off.
★High speed processing circuitry reads standard automotive parameters including duty cycle and pulse width making this tool ideal for testing fuel injection systems.
★Features auto-ranging, and data hold functions with overload protection on all ranges.
★Includes relative functions including Min/Max and Peak Hold.
Display: LCD Display with Backlight, 6000 counts
Operating Environment: 600V CAT IV and 1000V CAT III
DC Voltage Range: 600mV/6V/60V/600V/1000V
DC Voltage Resolution: 0.1mV/1mV/10mV/100mV/1V
AC Voltage Range: 6V/60V/600V/750V
AC Voltage Resolution: 1mV/10mV/100mV/1V
DC Current Range: 600μA/6mA/60mA/600mA/20.00A
DC Current Resolution: 0.01μA/0.01mA/0.1mA/10mA
AC Current Range: 60mA/600mA/20A
AC Current Resolution: 0.01mA/0.1mA/10mA
Frequency Range: 9.999Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz
Frequency Resolution: 0.001Hz/0.01Hz/0.1Hz/0.001KHz/0.01KHz/0.1KHz/0.001MHz
Resistance Range: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
Resistance Resolution: 0.1Ω/1Ω/10Ω/100Ω/1kΩ/10kΩ
Capacitance Range: 9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF/99.99mF
Capacitance Resolution: 0.001nF/0.01nF/0.1nF/1nF/10nF/100nF/0.1μF/0.001mF
Duty Cycle: 1%~99%
RPM (Tach): 60～12000RPM
DWELL ANGLE: 2CYL～8CYL
PULSE WIDTH: 1.0 ~ 10.0ms
Fuse: 800mA/20A
Diode Test:√
Continuity Buzzer:√
Data Hold:√
Back Light:√
Auto Power Off:√
℃/℉:√
True RMS:√
Data Hold MAX/MIN:√
USB connect PC:√
Working Temperature/Humidity: 0~40°C;
Storage Temperature/Humidity: -10~60°C;
Power Supply: 9V(6F22)*1(not included)
Item Size: 166*88*51mm
Item Weight: 320g
From the supplier
★This multifunctional multimeter with high precision and high performance can measure AC/DC voltage, current, resistance, capacitance, frequency, duty ratio. It also can test NCV(non-contact voltage), live line, diode, transistor and continuity.
★Includes new generation, 15-function, auto-ranging automotive diagnostic multimeter.
★Digital display gives accurate indication of component outputs.
★Large easy to read high contrast display with bright, white backlight.
★Workshop-tough, durable bi-composite case with integral stand and auto power shut-off.
★High speed processing circuitry reads standard automotive parameters including duty cycle and pulse width making this tool ideal for testing fuel injection systems.
★Features auto-ranging, and data hold functions with overload protection on all ranges.
★Includes relative functions including Min/Max and Peak Hold.
Display: LCD Display with Backlight, 6000 counts
Operating Environment: 600V CAT IV and 1000V CAT III
DC Voltage Range: 600mV/6V/60V/600V/1000V
DC Voltage Resolution: 0.1mV/1mV/10mV/100mV/1V
AC Voltage Range: 6V/60V/600V/750V
AC Voltage Resolution: 1mV/10mV/100mV/1V
DC Current Range: 600μA/6mA/60mA/600mA/20.00A
DC Current Resolution: 0.01μA/0.01mA/0.1mA/10mA
AC Current Range: 60mA/600mA/20A
AC Current Resolution: 0.01mA/0.1mA/10mA
Frequency Range: 9.999Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz
Frequency Resolution: 0.001Hz/0.01Hz/0.1Hz/0.001KHz/0.01KHz/0.1KHz/0.001MHz
Resistance Range: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
Resistance Resolution: 0.1Ω/1Ω/10Ω/100Ω/1kΩ/10kΩ
Capacitance Range: 9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF/99.99mF
Capacitance Resolution: 0.001nF/0.01nF/0.1nF/1nF/10nF/100nF/0.1μF/0.001mF
Duty Cycle: 1%~99%
RPM (Tach): 60～12000RPM
DWELL ANGLE: 2CYL～8CYL
PULSE WIDTH: 1.0 ~ 10.0ms
Fuse: 800mA/20A
Diode Test:√
Continuity Buzzer:√
Data Hold:√
Back Light:√
Auto Power Off:√
℃/℉:√
True RMS:√
Data Hold MAX/MIN:√
USB connect PC:√
Working Temperature/Humidity: 0~40°C;
Storage Temperature/Humidity: -10~60°C;
Power Supply: 9V(6F22)*1(not included)
Item Size: 166*88*51mm
Item Weight: 320g
