About this product
- Materials: plastic
- Size: 29mm*25.5mm
- Color: white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: plastic
- Size: 29mm*25.5mm
- Color: white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | plastic |
|---|---|
| Size | 29mm*25.5mm |
| Color | white |
From the supplier
Miniature size 20mm
PCB mounting
5KV/8mm insulation
Switching capacity 5A/10A
General purpose ,Industiral electronics
Low coil power consuption
Sealed
Contact materials AgSnO
Rated switching current (with resistive load ) :5A(2C/O) 10A(1C/O)
Max switching current (with resistive load ) :8A(2C/O) 12A(1C/O)
Rated volatage :250VAC/30VDC
initial Contact resistance :AgSnO ＜100mΩ（1A 6VDC）
Electrical Life:100,000 operations minimum(at full rated load)
Mechanical Life:1,000,000 operations minimum
Approved UL,CE
