Lug Resilient Seated Butterfly Valve Without Pin
HEBEI LEADING METALS & PIPING INDUSTRIES CO.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Lug Resilient Seated Butterfly Valve Without Pin
HEBEI LEADING METALS & PIPING INDUSTRIES CO.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Gray Iron, Ductile Iron, Carbon Steel, Stainless Steel
- Size: 2” - 12"
- Color: blue, black, red or other colors
- Valve stem: Normal
- Materialof seal surface: Other
- Application: WaterIndustrialUsage
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Gray Iron, Ductile Iron, Carbon Steel, Stainless Steel
- Size: 2” - 12"
- Color: blue, black, red or other colors
- Valve stem: Normal
- Materialof seal surface: Other
- Application: WaterIndustrialUsage
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Gray Iron, Ductile Iron, Carbon Steel, Stainless Steel |
|---|---|
| Size | 2” - 12" |
| Color | blue, black, red or other colors |
| Valve stem | Normal |
| Materialof seal surface | Other |
| Application | WaterIndustrialUsage |
| Work pressure | LowPressure(Pn<1.6MPa) |
| Seal form | ForceSealed |
| Structure | CentreSealing |
| Valve body | Other |
| Connection form | LugSupport |
| Working temperature | NormalTemperature(-40°C<T<120°C) |
| Driving mode | Other |
Product details
| Materials | Gray Iron, Ductile Iron, Carbon Steel, Stainless Steel |
|---|---|
| Size | 2” - 12" |
| Color | blue, black, red or other colors |
| Valve stem | Normal |
| Materialof seal surface | Other |
| Application | WaterIndustrialUsage |
| Work pressure | LowPressure(Pn<1.6MPa) |
| Seal form | ForceSealed |
| Structure | CentreSealing |
| Valve body | Other |
| Connection form | LugSupport |
| Working temperature | NormalTemperature(-40°C<T<120°C) |
| Driving mode | Other |
From the supplier
Butterfly Valves
Size:2＂-12＂
End Connection:Wafer
Body Material:Gray Iron(GG25), Ductile Iron(GGG40/50),Cast Steel(WCB),Stainless Steel(CF8,CF8M,CF3,CF3M)
Disc Material:Ductile Iron (Nickel Plated or Nylon Coated),Cast Steel(A216 WCB),Stainless Steel(CF8,CF8M,CF3,CF3M),Aluminum Bronze(C954)
Seat Material:EPDM, Buna-N(NBR), PTFE, Viton
Stem Material:SS410, SS416, SS304, SS316
Actuator:Handle Lever, Worm Gear, Pneumatic Actuator, Chain Operator
Standard:API 609, BS 5155,MSS SP-67/68, EN593
Working Pressure:Class 125/150, PN 10/16/25, 5K/10K/16K
From the supplier
Butterfly Valves
Size:2＂-12＂
End Connection:Wafer
Body Material:Gray Iron(GG25), Ductile Iron(GGG40/50),Cast Steel(WCB),Stainless Steel(CF8,CF8M,CF3,CF3M)
Disc Material:Ductile Iron (Nickel Plated or Nylon Coated),Cast Steel(A216 WCB),Stainless Steel(CF8,CF8M,CF3,CF3M),Aluminum Bronze(C954)
Seat Material:EPDM, Buna-N(NBR), PTFE, Viton
Stem Material:SS410, SS416, SS304, SS316
Actuator:Handle Lever, Worm Gear, Pneumatic Actuator, Chain Operator
Standard:API 609, BS 5155,MSS SP-67/68, EN593
Working Pressure:Class 125/150, PN 10/16/25, 5K/10K/16K
About the supplier
- ✓Exhibited at 9 of the last 10 Canton Fairs
- ✓Foreign Trade Company
- ✓Founded 2015
- Exhibited at 9 of the last 10 Canton Fairs
- Foreign Trade Company
- Founded 2015
