Limited, medium tension clamp for ADSS fiber optical cables
Vilun Electric Co.,Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Limited, medium tension clamp for ADSS fiber optical cables
Vilun Electric Co.,LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Aluminum alloy
- Size: 1500
- Color: Silver white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Aluminum alloy
- Size: 1500
- Color: Silver white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Aluminum alloy |
|---|---|
| Size | 1500 |
| Color | Silver white |
Product details
| Materials | Aluminum alloy |
|---|---|
| Size | 1500 |
| Color | Silver white |
From the supplier
Limited, MediumTension Clamp for ADSS Fiber Optical Cables
It has been designed to securely but gently terminate ADSS aerial fiber optical cable. A two component design consisting of appropriate size and length of Structure Reinforcing Rods and tension component is required to transfer axial tensile loads and distribute radial compressible forces through the plastic jacket and onto the internal strength members without damaging the fragile plastic jacket or internal optical fibers.
Limited Tension Clamp for ADSS Fiber Optical Cables
For use on:
Spans between 100m-200m, line corner≥25°, breaking strength:10kN.Double layer/thimble, PD link, U type shackle
Catalog Number
Product Model
Diameter Range(mm)
Cable Diameter Range
Length (mm)
Length
Average Weight(kg)
Weight
Color Code
Color Code
ANL 1070 010
10.2-10.7
1210
1.4
Black
ANL 1140 010
10.8-11.4
1210
1.5
Yellow
ANL 1220 010
11.5-12.2
1210
1.7
Green
ANL 1290 010
12.3-12.9
1210
1.9
Orange
ANL 1370 010
13.0-13.7
1210
2.0
Blue
ANL 1460 010
13.8-14.6
1210
2.1
White
ANL 1550 010
14.7-15.5
1210
2.1
Red
ANL 1650 010
15.6-16.5
1210
2.2
Black
ANL 1750 010
16.6-17.5
1210
2.3
Yellow
ANL 1870 010
17.6-18.7
1210
2.6
Green
ANL 1990 010
18.8-19.9
1210
2.6
Orange
ANL 2110 010
20.0-21.1
1210
2.6
Blue
ANL 2250 010
21.2-22.5
1210
2.7
White
ANL 2400 010
22.6-24.0
1210
2.9
Red
ANL 2550 010
24.1-25.5
1210
3.0
Black
ANL 2720 010
25.6-27.2
1500
3.3
Yellow
ANL 2890 010
27.2-28.9
1500
3.4
Green
ANL 3070 010
29.0-30.7
1500
3.5
Orange
ANL 3270 010
30.8-32.7
1500
3.6
Blue
Medium Tension Clamp for ADSS Fiber Optical Cables
For use on:
Spans between 200m-300m,line corner≥25°, breaking strength:15kN.Double layer/thimble, PD link, U type shackle
Catalog Number
Product Model
Diameter Range(mm)
Cable Diameter Range
Length (mm)
Length
Average Weight(kg)
Weight
Color Code
Color Code
ANL 1220 015
11.9-12.2
1800
2.6
Green
ANL 1290 015
12.3-12.9
1800
2.7
Orange
ANL 1370 015
13.0-13.7
1800
2.8
Blue
ANL 1460 015
13.8-14.6
1800
3.3
White
ANL 1550 015
14.7-15.5
2000
4.4
Red
ANL 1650 015
15.6-16.5
2000
4.6
Black
ANL 1750 015
16.6-17.5
2000
4.9
Yellow
ANL 1870 015
17.6-18.7
2000
5.0
Green
ANL 1990 015
18.8-19.9
2200
6.1
Orange
ANL 2110 015
20.0-21.1
2300
6.9
Blue
ANL 2250 015
21.2-22.5
2300
7.7
White
ANL 2400 015
22.6-24.0
2400
8.1
Red
ANL 2550 015
24.1-25.5
2400
8.4
Black
ANL 2720 015
25.6-27.2
2500
9.5
Purple
ANL 2890 015
27.3-28.9
2500
10.6
Pink Powder
ANL 3070 015
29.0-30.7
2600
11.3
Brown
ANL 3270 015
30.8-32.7
2700
12
Orange
The daily operating tension for high tension clamp is more than 8.9kN, please consult Vilun for more sizes and products not shown.
