LENTIL SPLIT MACHINE or LENTIL SPLITTING MACHINE is invented based on the world's large demand in lentil bran removing and lentil splitting.

　　The lentil (Lens culinaris) is an edible pulse. It is a bushy annual plant of the legume family, known for its lens-shaped seeds. There are brown lentil, black lentil, green lentil, red lentil and yellow lentils in the world.

　　How do we process lentils by lentil split machine? Usually we adopt the whole lentil cleaning, peeling and splitting line to clean, peel, split and package lentils.

　　1. Lentil Split Machine cleaning section: it adopts two screening sections, two destoning sections, one magnetic separation section, and removes the big, small and light impurities, pebbles and magnetic material from the beans to ensure the quality of the end products.

　　2. Lentil Split Machine color sorting section: it adopts the color sorter to separate the moldy kernels, shriveled beans and foreign species of beans according to the color and luster feature of the beans.

　　3. Lentil Split Machine peeling and splitting section: it adopts peeling, splitting, brushing and shunting technology (it can utilize the segregation valve to choose peeling and brushing according to the material character.)

　　1)Peeling and splitting: it can remove the bean bran, split the bean kernels and separate and collect corn kernels by effective aspiration system;

　　2)Brushing: it can separate the micro bran and dust which adheres to the material surface.

　　4. Lentil Split Machine Grading section: it adopts different screens and classify the material into different grades according to the size.

　　5. Lentil Split Machine Measuring and packaging section: storage can reduce the amount of labor used. Measuring can be artificial or electronic.

　　Lentil Split Machine Technical parameter:

Type

Power (kw)

Power Consumption(kw/h)

Capacity(t/24h)

Workshop Dimension(l*w*h/m)

10t

24

38-40

10

10*4*4 (steel structure)

20t

56

38-40

20

16*5*5 (steel structure)

30t

72

38-40

30

20*5*5 (steel structure)

50t

119

38-40

50

20*5*7 (steel structure)

100t

238

38-40

100

30*5*7 (steel structure)
