From the supplier
JS TOP RDC/FFG
High precision in parts and assembly；European configuration, low failure rate；Helical gear drive, high precision and long lifespan；Four times creasing, good folding effect；Non-Yoke creasing and slotting heads design；Fine creasing；Equipped with stripper, clean die-cutting scrap；Low power consumption, high-strength and lightweight design；High forming precision without folding beam deformation.
Technical Parameters and Main Features
Max. Design Speed：900 Series：300 sheets/min ；1200 Series：250 sheets/min
Standard Print Plate Thickness：7.2mm
Sheet Caliper：1.5-10mm
Accuracy：Feeding Accuracy：±1mm；Printing Registration：±0.5mm；Slotting Accuracy：±1.5mm；Die-cutting Accuracy：±1mm
JS TOP-QS RDC/FFG
Fixed type machine, top-printing；Feeding unit: non-crush servo lead edge feeder, brushes, suctionand electrostatic for dust removal；Printing unit: ceramic anilox roll and doctor blade system, ceram ic-coated wheels vacuum transfer, and full servo drive;Creasing unit: independent creasing unit, same diameter ofcreasing wheel, and Non-Yoke heads design；Oscillating Stripper: dual slotting mode, and Non-Yoke heads design；Die-cutting unit: die-cutting cylinder and anvil roll are driven independently to prevent impact from die-cutting to printing；Stripping unit: patented intensive wheel waste removal mechanism；Folding and forming unit: famous glue extrusion system, second ary forming and folding wheels design；Counting and ejecting unit: max counting and ejecting cycles: 30
Technical Parameters and Main Features
Max. Design Speed：900 Series：400 sheets/min ; 1200 Series：300 sheets/min
Standard Print Plate Thickness：7.2mm
Sheet Caliper：1.5-8mm
Accuracy：Feeding Accuracy：±1mm；Printing Registration：±0.5mm；Slotting Accuracy：±1.5mm；Die-cutting Accuracy：±1mm
JS BOT RDC
Open type machine, bottom-printing；Four-axis lead edge feeder, automatic adjustment of feeding stroke, electrostatic for dust removal；Vacuum transfer system with self-adaptive vacuum suction area；Equipped with conveyor unit, optionally available with IR or UV drying units；Independent drive of die-cutting cylinder and anvil roll, servo-controlled speed compensation, emery roller grinding device；DCS intelligent centralized control system with open connection to ERP.
Technical Parameters and Main Features
Max. Design Speed：200sheets/min
Die-cutting Accuracy：±1.0mm
Sheet Size：Max：1600X2800、Min：400x685mm
Maximum Printing Area：1560X2750/3150mm
Standard Print Plate Thickness：7.2mm
Sheet Caliper：1.5-8mm
JS PRINTER MINI RDC/FFG
Designed for small sheet, open type machine, top-printing；Feeding unit master touch screen, centralized control；Non-crush servo lead edge feeder；Non-Yoke slotting and creasing heads；DCS intelligent centralized control system with open connection to ERP.
Technical Parameters and Main Features
Max. Speed：350sheets/min
Max. Sheet Size：630X1800mm
Max. Sheet Size for Skip Feeding：870X1800mm
Print Plate Thickness：7.2mm（resin 3.94mm＋cushion 3.05mm＋film）
Sheet Caliper：1.5-8mm
Accuracy：Feeding accuracy: ±1mm，Printing registration: ±0.5mm Slotting accuracy: ±1.5mm, Die-cutting accuracy: ±1mm
