Hyundai HX220HD Excavator

Shanghai Sunight Machinery Co.,Ltd

3/10 fairsForeign Trade CompanyModel Hyundai HX220HD

Hyundai HX220HD Excavator

Price on request

The supplier hasn’t listed a price. We can get their current prices and MOQ.

Hire sourcing agent for this supplier See all sourcing services

Verify from $29 · written report in 3 business days · 100% refund if not satisfied

Service: From $29 per supplier (Verify)
You get: Phone and video verification, a quote sheet and a written report
Turnaround: 3 business days
Contact details: Sent to you once your request is confirmed

100% refund if not satisfied. The supplier pays us no commission on your order.

Hyundai HX220HD Excavator

Visit the Shanghai Sunight Machinery Co.,Ltd store

Hyundai HX220HD Excavator

Shanghai Sunight Machinery Co.,Ltd

3/10 fairsForeign Trade CompanyModel Hyundai HX220HD

Price on request

The supplier hasn’t listed a price. We can get their current prices and MOQ.

Hire sourcing agent for this supplier See all sourcing services

Verify from $29 · written report in 3 business days · 100% refund if not satisfied

Service: From $29 per supplier (Verify)
You get: Phone and video verification, a quote sheet and a written report
Turnaround: 3 business days
Contact details: Sent to you once your request is confirmed

100% refund if not satisfied. The supplier pays us no commission on your order.

About this product

Size: 9530mm×3190mm×3030mm
Color: Hyundai Original Color
Automatic grade: Non Automation
Walking mode: Crawler
Power source: Other
Customized: Non-Customized
Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries

About this product

Size: 9530mm×3190mm×3030mm
Color: Hyundai Original Color
Automatic grade: Non Automation
Walking mode: Crawler
Power source: Other
Customized: Non-Customized
Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries

Product details

Size	9530mm×3190mm×3030mm
Color	Hyundai Original Color
Automatic grade	Non Automation
Walking mode	Crawler
Power source	Other
Customized	Non-Customized
Engine type	Diesel Engine

Product details

Size	9530mm×3190mm×3030mm
Color	Hyundai Original Color
Automatic grade	Non Automation
Walking mode	Crawler
Power source	Other
Customized	Non-Customized
Engine type	Diesel Engine

From the supplier

Basic Information：The Hyundai HX220HD is a 22 - ton - class medium - sized crawler excavator with an operating weight of 21,420 kg. The bucket capacity ranges from 0.87 to 1.20 cubic meters, making it suitable for a variety of engineering work scenarios.
Power System：This excavator is equipped with a Hyundai 6BTAA - 5.9 diesel engine, with a rated power of 110 kW (148 hp) at 2,000 rpm and a maximum torque of 64 kgf·m at 1,300 rpm. It provides strong power, offering sufficient power support for various operations and also having good fuel economy.
Hydraulic System：The rated flow of the main pumps is 2×234 l/min, and the implement circuit pressure is 350 kgf/cm², enabling fast and precise hydraulic action control and improving work efficiency. The fuel tank has a capacity of 340 liters, and the hydraulic tank has a capacity of 160 liters, meeting the needs of long - time operation.
Operation Performance：The swing speed is 12.2 rpm, the travel speed is 5.7 km/h, the maximum traction force is 21,100 kgf, and the maximum gradeability is 35 degrees. The bucket digging force (ISO) is 15,500 kgf, and the arm digging force (ISO) is 10,900 kgf. It has a powerful digging and loading capacity, easily coping with various complex digging tasks.
Working Range：The maximum digging reach can reach 9,980 mm, the maximum digging depth is 6,730 mm, the maximum digging height is 9,600 mm, and the maximum dumping height is 6,780 mm, enabling efficient operation within a large range.
Structural Design：It adopts a reinforced box - section frame welding structure, using low - stress, high - strength steel, ensuring safety and resistance to external impacts when driving on rough ground and working in wet sites. At the same time, it is equipped with highly durable upper and lower rollers and track guards. In addition, the boom and arm have high durability and have passed strict field tests. No matter how harsh the working environment is, they can work reliably.
Operation Comfort：The cab adopts viscous mounting technology, effectively reducing the vibration and noise level inside the cab, providing a more comfortable driving experience for the operator and helping to improve the operator's work efficiency. The cab has a spacious space and good visibility, equipped with a comfortable seat, smooth travel pedals and footrests, an improved smart display, and an easy - to - operate control panel.
Maintenance Convenience：The HX220HD excavator is designed for easy maintenance. Engine components are easy to access, and the centralized electrical control unit and easy - to - replace air filter assembly reduce the difficulty and cost of maintenance. The left - and - right swinging side cover design facilitates daily inspection and maintenance work by staff.

From the supplier

Basic Information：The Hyundai HX220HD is a 22 - ton - class medium - sized crawler excavator with an operating weight of 21,420 kg. The bucket capacity ranges from 0.87 to 1.20 cubic meters, making it suitable for a variety of engineering work scenarios.
Power System：This excavator is equipped with a Hyundai 6BTAA - 5.9 diesel engine, with a rated power of 110 kW (148 hp) at 2,000 rpm and a maximum torque of 64 kgf·m at 1,300 rpm. It provides strong power, offering sufficient power support for various operations and also having good fuel economy.
Hydraulic System：The rated flow of the main pumps is 2×234 l/min, and the implement circuit pressure is 350 kgf/cm², enabling fast and precise hydraulic action control and improving work efficiency. The fuel tank has a capacity of 340 liters, and the hydraulic tank has a capacity of 160 liters, meeting the needs of long - time operation.
Operation Performance：The swing speed is 12.2 rpm, the travel speed is 5.7 km/h, the maximum traction force is 21,100 kgf, and the maximum gradeability is 35 degrees. The bucket digging force (ISO) is 15,500 kgf, and the arm digging force (ISO) is 10,900 kgf. It has a powerful digging and loading capacity, easily coping with various complex digging tasks.
Working Range：The maximum digging reach can reach 9,980 mm, the maximum digging depth is 6,730 mm, the maximum digging height is 9,600 mm, and the maximum dumping height is 6,780 mm, enabling efficient operation within a large range.
Structural Design：It adopts a reinforced box - section frame welding structure, using low - stress, high - strength steel, ensuring safety and resistance to external impacts when driving on rough ground and working in wet sites. At the same time, it is equipped with highly durable upper and lower rollers and track guards. In addition, the boom and arm have high durability and have passed strict field tests. No matter how harsh the working environment is, they can work reliably.
Operation Comfort：The cab adopts viscous mounting technology, effectively reducing the vibration and noise level inside the cab, providing a more comfortable driving experience for the operator and helping to improve the operator's work efficiency. The cab has a spacious space and good visibility, equipped with a comfortable seat, smooth travel pedals and footrests, an improved smart display, and an easy - to - operate control panel.
Maintenance Convenience：The HX220HD excavator is designed for easy maintenance. Engine components are easy to access, and the centralized electrical control unit and easy - to - replace air filter assembly reduce the difficulty and cost of maintenance. The left - and - right swinging side cover design facilitates daily inspection and maintenance work by staff.
