Apex 63T/1600 Electro-Hydraulic Press Brake: Stable & Precise, Versatile for All Sheet Metal Work

Apex 63T/1600 electro-hydraulic synchronous bending machine is a classic and cost-effective model carefully built by Nanjing Apex Intelligent Equipment Co., Ltd., targeting small and medium-sized sheet metal processing. With a 63-ton pressure rating and 1600mm effective working table length, it integrates electro-hydraulic proportional servo technology, reliable structure and intelligent control, and becomes the mainstream equipment for sheet metal bending in kitchen and bathroom, electrical cabinets, hardware, decoration, auto parts and other industries. The machine adheres to the enterprise manufacturing spirit of stability, precision, efficiency and durability, providing users with high-quality, easy-to-operate and low-cost bending solutions.

I. Core Structure: Heavy-Duty Design, Long-Term Precision

The whole machine adopts an integrated welded bed, which has undergone high-temperature annealing and vibration aging treatment to completely eliminate internal stress, ensuring no deformation under long-term heavy load and maintaining long-term machining accuracy. The key part adopts electro-hydraulic synchronous servo system with bilateral cylinder closed-loop control, which has strong anti-eccentric load capacity and stable operation. The machine is equipped with high-precision linear guides and hardened and ground ball screws, with smooth transmission and small backlash. The standard configuration of mechanical or hydraulic compensation mechanism effectively compensates for the bed deformation during bending, ensuring consistent angle accuracy of the whole workpiece.

II. Performance Parameters: Standard Configuration, Practical and Efficient

• Nominal pressure: 63T

• Working length: 1600mm

• Max. stroke: 100–120mm

• Opening height: 300–350mm

• Positioning accuracy: ±0.01mm

• Angle accuracy: ±0.5°
The equipment can bend various metal sheets such as carbon steel, stainless steel, aluminum alloy, etc. It can stably bend 4mm carbon steel and 2.5mm stainless steel in full length, which fully meets the daily processing needs of small and medium-sized sheet metal parts.

III. Electro-Hydraulic Advantage: Strong Power, Smooth Bending

Compared with ordinary mechanical bending machines, Apex 63T/1600 electro-hydraulic bending machine has stronger pressure, more stable speed and higher safety. The electro-hydraulic proportional valve controls the oil flow accurately, realizing stepless speed regulation of the slider, fast no-load descending and slow bending, which not only ensures efficiency but also protects the mold and workpiece. The bilateral synchronous error is extremely small, and the bending effect is straight and free of distortion. The hydraulic system is built with a pressure maintaining and overload protection function, which is safe and reliable for long-term continuous operation, and is not easy to generate heat and noise.

IV. Intelligent Control: Simple Operation, High Production Efficiency

The machine is equipped with a special CNC bending system, supporting multi-step programming, automatic calculation of bending depth, front and rear stopper position setting, and real-time display of working status. It supports quick mold replacement, breakpoint memory, power-off protection and one-key return to origin, which greatly reduces the operation difficulty. The X-axis rear stopper is driven by servo motor, with fast positioning and high precision, which can realize continuous bending of multiple processes. Workers can quickly master the operation, effectively reducing the labor intensity and improving the single-shift output.

V. Application Scenarios: Wide Adaptation, High Cost Performance

Apex 63T/1600 electro-hydraulic bending machine is widely used in many fields:

• Kitchen and bathroom industry: stainless steel sink, cabinet board, shelf, smoke hood shell

• Electrical and electrical: small electrical cabinet, switch box, instrument shell, distribution box cover

• Hardware decoration: metal door frame, advertising word bracket, decorative metal parts, furniture accessories

• Auto parts: small stamping parts, car interior sheet metal, motorcycle shell parts

• Daily hardware: toolbox, electrical box, metal support, various bending structural parts

VI. Quality and Service: Careful Manufacturing, Full-Service Support

The whole machine is manufactured in strict accordance with industry standards and quality management system. Hydraulic parts, electrical components and sealing parts adopt well-known brands to ensure stable performance and long service life. The machine has a simple structure, convenient maintenance, low wearing parts consumption and extremely low later use cost. Relying on the perfect after-sales system of Nanjing Apex Intelligent Equipment, the company provides on-site installation and commissioning, operator training, 24-hour technical consultation and rapid after-sales response, so that users can use it without worries.

Apex 63T/1600 electro-hydraulic bending machine combines stable electro-hydraulic technology, solid structural design and humanized operation. It is a high cost-effective bending equipment specially built for small and medium-sized processing enterprises, helping users improve product quality, expand processing capacity and win more market opportunities.
