Heron 220kVA Heat Press Welding Machine
Heron Intelligent Equipment Co.,LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 1800(L)*1350(H)*2420(W)
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
About this product
- Size: 1800(L)*1350(H)*2420(W)
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
Product details
| Size | 1800(L)*1350(H)*2420(W) |
|---|
Product details
| Size | 1800(L)*1350(H)*2420(W) |
|---|
From the supplier
Welding Machine Features:
1.This welder has one single welding head.It's easy to operate.
Operators' actual working needs are full considerate,improve work efficiency and reduce labor intensity.
2. Beside manually load and unload workpieces,the rest are automatic control.
Takt time/Each welding movements are short and high intensity,fully meet the process requirements of workpiece.
3.The welder has two control modes:manual and automatic.
With sound and light alarm, it's easier to operate and maintain the welder. Also have proportional valve and displacement sensors.
4.This welder uses Heron own inverter welding power and transformer.
All pneumatic components use FESTO (Germany ). Main control component PLC is Mitsubishi.
Touch screen is Schneider.Other electrical components use imported brands.So energy consumption has reduced up to 50% , welding quality and stability are improved.
5. Welder has detections in :
Secondary welding current;Transformer temperature detection; Cooling water flow;
Compressed air pressure detect; Workpiece anti-fool design; Electrode wearing detect.
Welder's service life has increased.Long term efficient working is ensured.
6 The working area are sealed up by European standard aluminum frame. A emergency stop has installed in the aluminum frame, so operate is much safer.
Main technical parameter :
Item
Parameter
Rated Capacity KVA
220
Power Supply V/φ/HZ
380/3P/50HZ
Max Input Current A
120
Rated Duty cycle %
20
Secondary Empty Voltage V
10.4
Secondary voltage adjust level
1
Throat Depth mm
420
Arm Gap mm
246
Cylinder Stroke mm
120
Electrode Size mm
100*8*8
Workpiece Size mm
35 *72
Welding Capacity mm
Welding Speed (s/ piece)
10
Max Working Pressure N/0.5MPa
6000
Compressed Air Pressure MPa
0.6
Compressed Air Consumption L/time (0.4MPa,Stroke 30mm)
3.56
Cooling Water Consumption L/MIN
12
Motor Power KW
Primary Cable
3*35+2*16 square meter
Max. Short Cut Current KA
4000
Dimension (L*W*H) mm
1800*1350*2420
