Features

■ 3-part differentiation of WBC, 20 parameters+3 histograms

■ 2 counting mode: whole blood and prediluted

■ Double apertures for WBC and RBC/PLT

■ Throughput: 60 samples per hour

■ Patented aperture technology: Automatic clog-clearing with high pressure and lower rate of clog

■ Up to 16000 sample results with histograms can be stored

■ Automatic diluting, lyzing, mixing, rinsing

■ Automatically cleaning sampling probe

■ Built-in thermal printer

■ 8.0”LCD with high resolution

■ Reagent alarm system (optional)

Technical Specifications

■ Parameters:

WBC, LY#, MID#, GR#, LY%, MID%, GR%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT,MPV, PDW, PCT, P-LCR and Histogram for WBC, RBC, PLT Coulter Principle

■ Method

Coulter Principle

Colorimetry hemoglobin determination

■ Performance

Parameter

Linearity   Range

Precision   (CV%)

WBC(109/ L)

0.0-99.9

2.5(7.0-15.0)

RBC(1012/L)

0.0-9.99

2.5(3.50-6.00)

HGB(g/L)

0-300

1.5(110-180)

MCV(fL)

40.0-150.0

0.5(80.0-110.0)

PLT(109/L)

0-999

5.0(200-500)

■ Menu

Review, Test, Maintenance, QC, Setup, Shutdown, Prime reagents, System diagnosis, Aperture rinse, Soak and rinse, Calibration Instrument config.

■  Sampler Volume

Predilute     20μL

Whole blood  15μL

■  Aperture Diameter

WBC     80μm

RBC/PLT  70μm

■  Dilution Rations

Whole   blood

Prediluted

WBC/HGB

1:333

1:676

RBC/PLT

1: 42143

1:85858

■ Carryover

WBC, RBC, HGB

■ Input/Output

1 RS232, 1 keyboard

■ Printout

Built-in thermal printer (2 optional print modes)

■ Operating Environment

Temperature15℃-30℃

Humidity 30%-85%

■ Power Requirement

AC100-240V,50/60Hz

■ Dimension

440mm(H)×350mm(W)×440mm(D)

■ Net Weight

17kg
