About this product
- Size: 600*500*400
- Color: green
- Power source: Other
- Cooling method: WindCooling
- Stroke: FourStrokes
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
About this product
- Size: 600*500*400
- Color: green
- Power source: Other
- Cooling method: WindCooling
- Stroke: FourStrokes
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
Product details
| Size | 600*500*400 |
|---|---|
| Color | green |
| Power source | Other |
| Cooling method | WindCooling |
| Stroke | FourStrokes |
Product details
| Size | 600*500*400 |
|---|---|
| Color | green |
| Power source | Other |
| Cooling method | WindCooling |
| Stroke | FourStrokes |
From the supplier
SPECIFICATION
Alternator Model
HPJ6500
Manufacture
CHONGQING HONPAN MACHINERY GROUP
ENGINE
Engine Brand
Engine Model
HP190F
Engine Type
Air-cooled, 4-cycle,Horizontal shaft, gasoline, OHV, cast iron cylinder liner, aluminum block
HP/CC
16Hp/ 420cc
Starting System
Electric
Ignition Model
Transistorized Magneto
Oil Capacity U.S.L(qt)
1.1
DC Output
12V-8.3A
Fuel Tank Capacity
25
ALTERNATOR
Vol, Reg. System
AVR
Output Voltage(V)
230V/220V
Output Frequency(Hz)
50Hz/60Hz
Rated Ampere(A)
25
Rated output(W)
5000
Maximum output(W)
5500
Insulation level
F level
Rated Power Factor
COS∮=1.0
Sound level Db
50
Phase
Single
Running hours
9 hrs
DIMENSIONS
(LXMXH) (mm)
850x540x770
Dry Weight (kg)
125
Wheel Size (inch)
10
Container Loading 20GP/40HQ
80/160
OPTIONS
Total Harmonic Distortion %
＜5%
Hour meter/VFT meter
optional
Three phase/ Remote Control
optional
From the supplier
SPECIFICATION
Alternator Model
HPJ6500
Manufacture
CHONGQING HONPAN MACHINERY GROUP
ENGINE
Engine Brand
Engine Model
HP190F
Engine Type
Air-cooled, 4-cycle,Horizontal shaft, gasoline, OHV, cast iron cylinder liner, aluminum block
HP/CC
16Hp/ 420cc
Starting System
Electric
Ignition Model
Transistorized Magneto
Oil Capacity U.S.L(qt)
1.1
DC Output
12V-8.3A
Fuel Tank Capacity
25
ALTERNATOR
Vol, Reg. System
AVR
Output Voltage(V)
230V/220V
Output Frequency(Hz)
50Hz/60Hz
Rated Ampere(A)
25
Rated output(W)
5000
Maximum output(W)
5500
Insulation level
F level
Rated Power Factor
COS∮=1.0
Sound level Db
50
Phase
Single
Running hours
9 hrs
DIMENSIONS
(LXMXH) (mm)
850x540x770
Dry Weight (kg)
125
Wheel Size (inch)
10
Container Loading 20GP/40HQ
80/160
OPTIONS
Total Harmonic Distortion %
＜5%
Hour meter/VFT meter
optional
Three phase/ Remote Control
optional
