Product description

Greenhouse-king series tractor are designed for greenhouse and garden specially, this tractor have all the functions as other tractors. It is the ideal machine for greenhouse and gardens. Small size, it has compact structure and small radius of turning circle. The two driving wheel can drive at the same time which suit for different kind of road conditions.

Specification for 50-80hp garden tractor

Product model

DS504

DS604

DS704

DS804

Wheel drive

4x4

Dimension(L*W*H)

3655x1420x2120 mm

Weight

1640 kg

Front wheel Tread

1070 mm

Rear Wheel

1065(1000-1300 mm)

Wheel Base

1900 mm

Min Land Clearance

235 mm

Gear shifts

12F+12R

Tyre Size

6.0-12/11.2-16

Steering gear

Hydraulic steering

Rear Suspension

Three-point Suspension

Engine Specification

Model

QC4102

QC4105

QC4108T70

QC4108T80

Type

Water cooled ,Vertical,4 stroke and Direct injection

Rated Power(kW)

36.7

44.11

51.5

58.82

Rated Revolution

2300/2400 (r/min)

Start Way

Electricity Start

Transmission

4×3×(1+1) shifts

Clutch

Double stage clutch

PTO Speed

6 spline 540/720

Company overview

Weifang Huaxia Tractor Manufacturing Co.,Ltd. Is located in the world’s capital of kite and the city of green power-Weifang. It is in the Economic Development Area of Weifang and only 3 kilometers to the expressway station of Weifang West, the traffic is very convenient

The area of the company and its factory is about 200,000 square meters and is one modern private enterprise with research, production and sale. The company has pursued perfect and done things seriously. It has the courage of innovation and has insisted on the production idea of high standard and high quality so its products have been optimized and upgraded constantly. And then the enterprise has developed and grown strong steadily. The company has strong technology force and superior machine and equipments with the auto assembly line which is advanced in China. The products are in strict compliance with the international norms of quality system and have mature guarantee service system so they have adopted 2000 edition ISO9001 international quality management system certificate. Further more, HUAXIA brand products have ever been awarded national patents ten times by the State Intellectual Property Office.

Package details

Complete tractor package. 2 units/20GP, 4 units/40HQ

FAQ

(1). Manufacturer or Trading Company

We are a leading tractor manufacturer for 20 years, and specialize in 12-240Hp tractors in China.

(2). MOQ

Mini tractor: 8 units

middle tractor(25-40hp): 2 units

Above 50hp: 1 unit

(3). Spare Parts

Free toolbox and easy damaged parts.

(4). Shippment

We can help you arrange shippment.

(5). Delivery Time

Usually 25 days.  In peak season,30-40 days

(6). Warranty Time

Complete service system, 12 months since arrival of destination port

(7). Payment Terms

We accept 30%T/T in advance, and 70% T/T before delivery

(8). Tractor Options

Can be equipped with ROPS, Canopy, Cabin, AC Cabin, Air Brakes, Hydraulic Valve Out, Paddy Tire or as per your requirements.

(9). Tractor Logo

We have our own logo. And we also can put your logo for free.

(10). Package and Loading

1.complete tractor package: 2 units/20GP, 4 units/40HQ

2.Iron Frame Package: 8 units/20GP, 16 units/40HQ

(11). Tractor Implements

Rotary tiller, disc plow, furrow plow, cultivator, front end Loader, backhoe, Mower, Trailer, Snow Blower or as per your requirements.

(12). Part supply

Complete Parts Workshop, and can supply all parts
