About this product
- Materials: Wire
- Size: 1X30M
- Color: gray
- Galvanized surface treatment: Hot-galvanizeCold-galvanizing
- Material: Other
- Stamping expanded metal mesh category: Other
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Wire
- Size: 1X30M
- Color: gray
- Galvanized surface treatment: Hot-galvanizeCold-galvanizing
- Material: Other
- Stamping expanded metal mesh category: Other
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Wire |
|---|---|
| Size | 1X30M |
| Color | gray |
| Galvanized surface treatment | Hot-galvanizeCold-galvanizing |
| Material | Other |
| Stamping expanded metal mesh category | Other |
| Application | Other |
| Hot-galvanize technique | Other |
| Surface treatment | Other |
| Hole shape | Other |
| Weight | Middle-weight |
| Weave characteristic | Other |
| Usage | ProtectionRoadConstructionCivilBuilding |
| Specifications | Roll |
Product details
| Materials | Wire |
|---|---|
| Size | 1X30M |
| Color | gray |
| Galvanized surface treatment | Hot-galvanizeCold-galvanizing |
| Material | Other |
| Stamping expanded metal mesh category | Other |
| Application | Other |
| Hot-galvanize technique | Other |
| Surface treatment | Other |
| Hole shape | Other |
| Weight | Middle-weight |
| Weave characteristic | Other |
| Usage | ProtectionRoadConstructionCivilBuilding |
| Specifications | Roll |
From the supplier
Specification of Welded Wire Mesh
Opening
Wire Diameter BWG
In inch
In metric unit(mm)
1/4" x 1/4"
6.4 x 6.4mm
BWG24-22
3/8" x 3/8"
10.6x 10.6mm
BWG22-19
1/2" x 1/2"
12.7 x 12.7mm
BWG23-16
5/8" x 5/8"
16x 16mm
BWG21-18
3/4" x 3/4"
19.1 x 19.1mm
BWG21-16
1" x 1/2"
25.4x 12.7mm
BWG21-16
1-1/2" x 1-1/2"
38 x 38mm
BWG19-14
1" x 2"
25.4 x 50.8mm
BWG16-14
2" x 2"
50.8 x 50.8mm
BWG15-12
2” x 4"
50.8 x 101.6mm
BWG15-12
4” x 4"
101.6 x 101.6mm
BWG15-12
4” x 6"
101.6 x 152.4mm
BWG15-12
6” x 6"
152.4 x 152.4mm
BWG15-12
6” x 8"
152.4 x 203.2mm
BWG14-12
Roll Width: 0.4m to 2m; Roll Length: 5m,10m,30m,etc.
Material: galvanized, PVC coated, stainless steel.
Note: Special specifications can be made according to customers requires.
From the supplier
Specification of Welded Wire Mesh
Opening
Wire Diameter BWG
In inch
In metric unit(mm)
1/4" x 1/4"
6.4 x 6.4mm
BWG24-22
3/8" x 3/8"
10.6x 10.6mm
BWG22-19
1/2" x 1/2"
12.7 x 12.7mm
BWG23-16
5/8" x 5/8"
16x 16mm
BWG21-18
3/4" x 3/4"
19.1 x 19.1mm
BWG21-16
1" x 1/2"
25.4x 12.7mm
BWG21-16
1-1/2" x 1-1/2"
38 x 38mm
BWG19-14
1" x 2"
25.4 x 50.8mm
BWG16-14
2" x 2"
50.8 x 50.8mm
BWG15-12
2” x 4"
50.8 x 101.6mm
BWG15-12
4” x 4"
101.6 x 101.6mm
BWG15-12
4” x 6"
101.6 x 152.4mm
BWG15-12
6” x 6"
152.4 x 152.4mm
BWG15-12
6” x 8"
152.4 x 203.2mm
BWG14-12
Roll Width: 0.4m to 2m; Roll Length: 5m,10m,30m,etc.
Material: galvanized, PVC coated, stainless steel.
Note: Special specifications can be made according to customers requires.
