G Series Whole Cover Laser Cutting Machine
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
G Series Whole Cover Laser Cutting Machine
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: metal
- Color: white black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shandong, China
About this product
- Materials: metal
- Color: white black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Shandong, China
Product details
| Materials | metal |
|---|---|
| Color | white black |
Product details
| Materials | metal |
|---|---|
| Color | white black |
From the supplier
WhatsAPP/Wechat/Mobile:+86 17860543384Technical ParametersMachine ModelLF3015G LF4020G LF6025Glaser power1000W 2000W 3000W 4000W 6000W 8000W(Optional)Dimensions8150*2825*2125mm 10255*3340*2125mm 14593*3843*2347mmworking area3000mm * 1500mm 4000mm*2000mm 6000mm*2500mmRepeat positioning accuracy±0.02mmMax speed120m/minMax acceleration1.5GVoltage and frequency380V 50Hz/60HzAuto Focus Laser Cutting Head
Without Manual Focusing
The software automatically adjusts the focusing lens to realize automatic perforating and cutting plates of different thickness. The speed of automatically adjusting focus lens is ten times of the manual adjusting.
Bigger Adjustment Range
Adjustment range -10 mm~ +10mm, precision 0.01mm, suitable for 0 ~ 20mm different types of plates.
Long Service Life
Collimator lens and focus lens both have water-cooling heat sink which reduces the temperature of the cutting head to improve the life of the cutting head.
Plate Welding Heavy Work Bed
Annealed And Heat Treated
Plate welding heavy work bed, no deformation in 20 years, suitable for ultra-high power 10,000-watt laser. The increase in weight is very beneficial to the laser cutting machine cutting speed.
Innovative Four Slings Working Bed
For reducing damage to the work bed during laser working, G.WEIKE Innovated the new work bed by adding four slings, and the life span of the fiber laser cutting machine work bed will be doubled.
8000W IPG Fiber Lasers Source
World Famous Brand
GWEIKE laser cutting machine YLS-CUT series high power fiber laser of IPG. Powerful cutting ability with stainless stell, aluminum and other metal materials, cutting thickness is up tu 40mm.
Long Service Life
The world leading IPG laser has stable performance, the service life can reach 100000 hours, and the overall quality of the equipment can be guaranteed safely.
Stable Cutting Performance
Fiber laser source can produce excellent beam quality, finer cutting lines, higher working efficiency and better machining quality. Fully closed constant temperature working environment makes laser source more effective to ensure the stable operation.
Industry Applications
LF3015G fiber laser cutting machine can carry up to 8000W laser power, so cutting some thick plate, it is a very good choice. For example, agricultural machinery, textile machinery, food machinery and construction machinery and other large machinery and equipment manufacturing, usually use high power fiber laser cutting machine for processing. Suitable for stainless steel, carbon steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel, aluminum-plating, zinc plate, copper and other metals
From the supplier
WhatsAPP/Wechat/Mobile:+86 17860543384Technical ParametersMachine ModelLF3015G LF4020G LF6025Glaser power1000W 2000W 3000W 4000W 6000W 8000W(Optional)Dimensions8150*2825*2125mm 10255*3340*2125mm 14593*3843*2347mmworking area3000mm * 1500mm 4000mm*2000mm 6000mm*2500mmRepeat positioning accuracy±0.02mmMax speed120m/minMax acceleration1.5GVoltage and frequency380V 50Hz/60HzAuto Focus Laser Cutting Head
Without Manual Focusing
The software automatically adjusts the focusing lens to realize automatic perforating and cutting plates of different thickness. The speed of automatically adjusting focus lens is ten times of the manual adjusting.
Bigger Adjustment Range
Adjustment range -10 mm~ +10mm, precision 0.01mm, suitable for 0 ~ 20mm different types of plates.
Long Service Life
Collimator lens and focus lens both have water-cooling heat sink which reduces the temperature of the cutting head to improve the life of the cutting head.
Plate Welding Heavy Work Bed
Annealed And Heat Treated
Plate welding heavy work bed, no deformation in 20 years, suitable for ultra-high power 10,000-watt laser. The increase in weight is very beneficial to the laser cutting machine cutting speed.
Innovative Four Slings Working Bed
For reducing damage to the work bed during laser working, G.WEIKE Innovated the new work bed by adding four slings, and the life span of the fiber laser cutting machine work bed will be doubled.
8000W IPG Fiber Lasers Source
World Famous Brand
GWEIKE laser cutting machine YLS-CUT series high power fiber laser of IPG. Powerful cutting ability with stainless stell, aluminum and other metal materials, cutting thickness is up tu 40mm.
Long Service Life
The world leading IPG laser has stable performance, the service life can reach 100000 hours, and the overall quality of the equipment can be guaranteed safely.
Stable Cutting Performance
Fiber laser source can produce excellent beam quality, finer cutting lines, higher working efficiency and better machining quality. Fully closed constant temperature working environment makes laser source more effective to ensure the stable operation.
Industry Applications
LF3015G fiber laser cutting machine can carry up to 8000W laser power, so cutting some thick plate, it is a very good choice. For example, agricultural machinery, textile machinery, food machinery and construction machinery and other large machinery and equipment manufacturing, usually use high power fiber laser cutting machine for processing. Suitable for stainless steel, carbon steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel, aluminum-plating, zinc plate, copper and other metals
About the supplier
Main products: Laser Processing Equipment, Other CNC Machine Tools and Additive Manufacturing Equipment, Flexible Manufacturing Units, Production Lines, Machining Centers, Welding and Cutting Robots, CNC Machine Tools
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Manufacturer
- ✓Founded 2004
- ✓Canton Fair Premium Supplier
- ✓CF Award winner
- ✓Brand exhibitor
- ✓National high-tech enterprise
- ✓Green booth award
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 2004
- Canton Fair Premium Supplier
