Fully Automatic Milk Juice Carton Filling Machine
- FOB goods (100)
- $22,500,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $787,500
- Section 301 tariff (25.0%)
- $5,625,000
- Customs fees (MPF/HMF)
- $28,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Fully Automatic Milk Juice Carton Filling Machine
- FOB goods (100)
- $22,500,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $787,500
- Section 301 tariff (25.0%)
- $5,625,000
- Customs fees (MPF/HMF)
- $28,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Size: 4*1.4*2.8m
- Color: silver
- Dosing device: Plunger
- Automatic grade: Fully AutomaticHand PressureSemi-Automatic
- Packaging type: Other
- Packaging container lifting structure: Chute Pneumatic Combination LiftingChute LiftingPneumatic Lifting
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea
- Made in: Liaoning, China
About this product
- Size: 4*1.4*2.8m
- Color: silver
- Dosing device: Plunger
- Automatic grade: Fully AutomaticHand PressureSemi-Automatic
- Packaging type: Other
- Packaging container lifting structure: Chute Pneumatic Combination LiftingChute LiftingPneumatic Lifting
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea
- Made in: Liaoning, China
Product details
| Size | 4*1.4*2.8m |
|---|---|
| Color | silver |
| Dosing device | Plunger |
| Automatic grade | Fully AutomaticHand PressureSemi-Automatic |
| Packaging type | Other |
| Packaging container lifting structure | Chute Pneumatic Combination LiftingChute LiftingPneumatic Lifting |
| Filling principle | Vacuum |
| Structure | LinearRotary |
| Packaging material | FilmAluminum FoilComposite Materials |
| Material type | GranularLiquidPowderSolid |
| Filling valve head | Single-HeadMulti-Head |
| Feed cylinder structure | Multi-Room FeedingSingle-Room Feeding |
From the supplier
BW-3000 type Gable Top Carton Filling Packing Machinery is fully automatic with top configuration. The entire machine is made of 304 food-grade stainless steel. The surface is special processed, so the appearance is beautiful.
1. Work flow :
Put cardboard into carton holder (manually) → Bottom preforming → Bottom heating and sealing → Ultrasonic capping (Optional)→Filling → Top preforming → Top heating and sealing → Date printing → Finished product
The whole process is controlled by PLC, and only need one person to operate.
2. Suitable for filling:
Milk, yogurt, cream, soya been milk, beaten egg, etc.
3. Technical parameter:
Capacity
250ml, 500ml, 750ml, 1000ml, 1200ml, 1500ml, 2000ml
Output
2000-2500 cartons/h
Packing material
A Type carton
Shelf life
milk, yogurt: 7--21days ( 2-6°C storage)
acid juice: 30–60 days (2-6°C storage)
whipped cream: 12 months (-18°C storage)
Capping
With capping (Optional)
Filling temperature
Under 50 degree centigrade
Overall power
25KW (three phases of power electricity)
Compressed air
Pressure: 1.0-1.4 Mpa
Flow rate: 1.4-2M3/min
Cooling water
Flow volume: ≥40L/ min
Temperature: ≤15°C
Size: (L*W*H)
3.7m*1.6m*2.8m
Net Weight
3500kg
Installation requirement
Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not
need to make angle.
4. Function:
1. PLC control, only need one worker.
2. Apply Touch screen which shows the relevant information for operator, and makes the operation easy.
3. Automatically record the working status, and can be long-term saved.
4. Automatic lubrication.
5. Automatically failure alarm, diagnosing, and solution indicating.
6. The filling capacity can be adjusted at will.
7. The capping function is optional.
8. Can be installed with remote debugging system, which can solve problems for long distance customers.
