Machine parameters
Machine model: FL-460
Laser tube power: 50W/60W/80W
Engraving speed: 0-1000mm/s
Supported software: Coreldraw, Photoshop, AI, CAD ETC.
Body weight: 90kg
Cooling method: water pump or constant temperature water tank and protection system
Laser tube type: CO2 glass laser tube
Engraving format: 400mm x 600mm
Cutting speed: 0-400mm/s
Rated voltage: 110/220V±10% 50/60Hz
Working environment temperature: 0℃ - 45℃
Positioning accuracy: ≤0.01mm

Applicable materials and industries
1. Non-metallic materials industry, such as: rubber printing, horn printing, wood printing, red plastic printing, organic glass printing, atomic printing and other materials on the lettering and engraving machine;
2. On electronic components, such as: engraving name, model, logo, pattern, etc.
3. Used for small-area craft processing, such as: engraving text and patterns on two-color board wood, bamboo slips, acrylic, leather, ABS plastic, crystal, jade and other materials.

Machine features
1. High-quality optical transmission system:
The whole machine adopts flying optical path design, and the optical lens adopts imported reflector, which reduces the loss of laser in the transmission process, and uses imported focusing mirror to achieve high-quality focusing of the light spot, providing a smaller and finer light spot for the machine to work, ensuring refined scanning and cutting effects.
2. Scientific design and installation process:
Friendly man-machine work area design: The laser head adopts a closed design and is equipped with an air blowing cooling system. During the work process, it can prevent dust from polluting the internal optical lens, and use the air blowing system for cooling and cooling, realizing 24-hour continuous work. Customers can choose the red light positioning device to achieve fast and accurate positioning during the work process and improve the accuracy of positioning. Reasonable auxiliary system design: The dust extraction and smoke exhaust system, water circulation cooling system, and power supply system are all integrated at the back of the machine, which is conducive to customers to install the machine and save space.
3. High-precision and stable motion system: The perfect combination of highly stable stepper motor and drive system and high-precision guide rail enables the machine to maintain high accuracy while working at high speed, achieving a perfect combination of accuracy and speed, and meeting customers' dual standards for speed and accuracy.
