F3000 cement mixer truck 6×4, SX5255GJBDR384 (WP10.340E22+PTO/Europe II), hydraulic main seat, four-point hydraulic suspension cab, electronically controlled automatic constant temperature air conditioner, electric window shaker, manual flip, ordinary air filter, metal bumper, 165Ah maintenance-free battery, spare tire holder, accelerator teleoperation (electronically controlled engine), 10JSD180 gearbox, 9.5T MAN front axle, 16T MAN double reduction axle, ratio 5.92, 850×300 (8+7) double layer frame, front and rear multi-leaf springs, four main springs + four U-bolts, 300L aluminum alloy fuel tank, 12.00R20 tires, mixing tank capacity 10 cubic meters , suitable for highway roads or simple paved roads.

F3000 cement mixer truck 8×4, SX5315GJBDT306 (WP10.380E22+PTO/Europe II), hydraulic main seat, four-point hydraulic suspension cab, electronically controlled automatic constant temperature air conditioner, electric window shaker, manual flip, ordinary air filter, metal bumper, 165Ah maintenance-free battery, spare tire holder, accelerator teleoperation (electronically controlled engine), 10JSD180 gearbox、9.5T MAN front axle, 16T MAN double reduction axle, ratio 5.262, 850×300 (8+7) double-layer frame, front and rear multi-leaf springs,four main springs + four U-bolts, 300L aluminum alloy fuel tank, 12.00R20 tires, mixing tank capacity 12 cubic meters, suitable for highway roads or simple paved roads.

Power

The project "Key Technologies and Applications of Power Assembly for Heavy Commercial Vehicles" won the first prize of National Award for Science and Technology Progress. Weichai is the largest power assembly group in China and the world's largest manufacturer of high-speed high-power engines, and currently has more than 3.5 million units worldwide. FAST is the world's largest manufacturer and distributor of heavy-duty transmission, and the annual production and sales of heavy-duty vehicle transmission ranks first in the world for twelve consecutive years, with more than 7 million units in the global market. HANDE axle is an important heavy-duty axle production base in China. It has produced more than 3.9 million axles, ranking first in the export of domestic axle assemblies for many years.

1.Weichai four-valve engine has strong power with large output torque, at lower engine speed. It is the best power and explosive force in the industry. Wedge suspension is equipped in engine, The NVH performance (noise, vibration and roughness of acoustic vibration), anti-loosening performance, comfort and vehicle reliability is greatly improved.

2.Fast transmission has dual intermediate shafts with high reliability. Large speed ratio range is suitable for different working conditions. And has strong climbing ability. The small speed ratio differential guarantees high fuel economy.

3.The fatigue life of HANDE axle is 1318,000 times and the bearing capacity is strong. The axle adopts the European synchronous FAG low resistance maintenance-free bearing technology with independent lubrication system, lower fuel consumption.

Chassis

1.It adopts 9.5T front suspension plate spring with large carrying capacity and high stiffness.

2.It adopts 850×300（8＋7）drive-through type of frame with high bending resistance and strong bearing capacity

3.The maximum turning angle of the front wheel is 46 degrees, the turning radius is small and the head is well-adjusted.

4.The approach angle and departure angle are 30 degrees and 28 degrees respectively, adaptable to the road conditions, and the trafficability is enhanced.

5.Low roll-resistance tires improve grip and have good anti-slip properties.

6. The use of flat tank and optimum layout further improves the ground clearance with better trafficability.

7.Large rim offset (183mm) with 16mm thickness of rim can reduce the risk of "wear-out" of the rear tire.

Upper Parts

Various tanks can be selected and the maximum volume is 16-square:

A. 5~7 cubic meters are mainly used for bridges, tunnels, sporadic projects, and other projects affected by the working environment. This vehicle is powered by a power-train (diesel).

B. 8~10 cubic meters currently are the most important market demand model, mainly for 6X4 chassis.

C. 12~14 cubic meters are used for long distance transportation, mainly for 8×4 chassis,.

2.Hydraulic system: Imported hydraulic pump, hydraulic motor, and reducer are three major hydraulic systems, with good quality, high reliability.

3.It is equipped with standard radiator (18L), The heat zone can be chosen as 26L, which has good heat dissipation effect and high working efficiency.
