Technical parameters:

1. Working voltage: AC 110V ~AC 250V.

2. Working current: 0~10A or 0~ 16A.

3. Specifications and models: 2P-5 hole 10A, 1P-3 hole 16A.

4. Working environment: Temperature-10~+55 ° C, relative humidity 10%~95%RH.

5. Working power consumption: 0.5W MAX.& nbsp;

6. Working frequency: 50/60Hz.& nbsp;

7. Wireless frequency range: 426.6MHZ-439.4MHZ.

8. Wireless receiving sensitivity: -90dbm.& nbsp;

9. Maximum wireless transmit power: 18dbm.& nbsp;

Main functions:

1. Directly connect to AC 160V ~ 250V, no additional power supply adapter is needed.& nbsp;

2. Built-in communication module, you can complete remote communication functions without connecting any external communication equipment.& nbsp;

3. Replace the original ordinary socket, easy installation, self-networking, and flexible deployment.& nbsp;

4. It has remote power on and off control functions.& nbsp;

5. It has the functions of temperature monitoring and poor contact protection of line plug interface.& nbsp;

6. It has the function of monitoring power consumption conditions such as voltage, current, power, etc. nbsp;

7. It has protection functions such as overcurrent, overload, and over-temperature.

8. It has power statistics and power statistics functions.& nbsp;

9. The socket has a relay function, which makes it convenient for a single fire switch to realize relay communication needs

Application scenarios:

1. Office electrical socket management

2. Intelligent management of home appliances

3. Intelligent control management of terminal electrical appliances in large government agencies and units
