Core performance parameters
Material properties: The main component is rigid polyvinyl chloride (UPVC), with the addition of stabilizers, antioxidants and other additives. It features corrosion resistance, no rusting and light weight (density approximately 1.38g/cm³).
Temperature range: The applicable medium temperature is usually -10 ℃ to 60℃. When it exceeds 80℃, it is prone to softening and deformation and cannot be used in hot water pipeline systems.
Pressure rating: It is classified into different pressure ratings based on wall thickness. Common ones include PN1.0MPa and PN1.6MPa. It should be used in conjunction with UPVC pipes of the same grade to prevent rupture caused by overpressure.
Connection method: Socket bonding is mainly used. The socket of the elbow is connected to the pipe socket through special UPVC glue. For some large-diameter products, flange connection can be adopted.

Nominal Size (GB Standard)

Common Inner Diameter Common Outer Diameter

Imperial Size

ABS Pipe: 3mm Wall Thickness Pipe UPVC:HDPE 1/2 inch DN15 20 1/2 3/4 inch DN20 25 3/4 1 inch DN25 32 1 1 1/4 inch DN32 40 1 1/4 1 1/2 inch DN40 50 1 1/2 2 inch DN50 63 2

2 1/2 inch

DN65 75 2 1/2 3 inch DN80 90 3 4 inch DN100 110 4 5inch DN125 140 5 6 inch DN150 160 6 8 inch DN200 225 8 10 inch DN250 280 10 12 inch DN300 315 12

Zhejiang Shuiyou Pipeline Valve Co., Ltd. is a well-known professional supplier of engineering plastic pipeline systems in China. The company produces and sells :UPVC pipelines; ABS pipeline PP-H pipeline CPVC pipelines, the company's products are widely used in various fields such as the chemical industry, electronic semiconductors, biomedicine, environmental water treatment, air conditioning circulating water, air-raid shelter drainage, steel and metallurgy, etc.
Zhejiang Shuiyou Pipeline Valve Co., Ltd. has always adhered to taking the interests of customers as the foundation of its development, keeping its promises. The company has always been committed to providing customers with the most suitable pipeline solutions for the operation rules of their enterprises and the most concise and satisfactory ones with reliable product quality, high-quality service models, and highly qualified professional technical personnel.
"Rigorous, pragmatic, proactive and efficient", the company advocates the enterprise philosophy of "people-oriented" and "quality first", takes science and technology as the core, develops scale economy, strives to open up the path of global integrated market, ranks among the world's first-class building materials enterprises, and takes the revitalization of national industry as its responsibility. Our company sincerely welcomes people from all walks of life, new and old customers to contact us by phone, letter or in person to discuss business. We express our heartfelt gratitude!
Corporate Philosophy: With a professional heart, do professional things!
