Digital mixing console
HMAUDlO Jiujiang Electronic Technology Co.,Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
Digital mixing console
HMAUDlO Jiujiang Electronic Technology Co.,Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Size: 630*525*309(mm)
- Color: black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Jiangxi, China
About this product
- Size: 630*525*309(mm)
- Color: black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Jiangxi, China
Product details
| Size | 630*525*309(mm) |
|---|---|
| Color | black |
Product details
| Size | 630*525*309(mm) |
|---|---|
| Color | black |
From the supplier
▼ 15.6-inch capacitive touch screen with 1920×1080 resolution, professional-grade display accuracy, precise fingertip control, and clear visual presentation.
▼ 13 dust-proof track-mounted motorized faders with 100mm travel for precise level control, offering smooth operation with no stepped feel.
▼ Total 22/26/34 physical signal inputs, including 20/24/32 XLR analog input channels with microphone preamps (featuring 8 COMBO jacks) and 1 stereo USB playback channel.
▼ Total 12/12/20 physical signal outputs, including 8/8/16 XLR analog output channels, 1 stereo TRS headphone monitor output, and 1 USB recording channel.
▼ Equipped with a selectable Bluetooth/audio card input module for convenient on-site audio playback from mobile phones or computers.
▼ 22 mixing buses, consisting of 14 mono buses, 4 effects buses, 2 mono MTRX matrix output buses, and 1 stereo main output bus.
▼ Input channels support 48V phantom power switching, analog gain, digital gain, phase inversion, 0–1000ms delay, pan/balance, level control, custom channel labeling, 5-band parametric EQ (switchable between parametric EQ, high shelf, low shelf, high-pass, and low-pass), noise gate, compressor, RTA, RTA freeze, and all-pass filter.
▼ Output channels support 0–1000ms delay, pan/balance, level control, custom channel labeling, 6-band parametric EQ (switchable between parametric EQ, high shelf, low shelf, high-pass, and low-pass), compressor, RTA, RTA freeze, and all-pass filter.
▼ Newly added channel freeze function for quickly locking the current RTA status of a channel, facilitating frequency response observation during complex live performances.
▼ Newly added channel all-pass filter function for precise phase control, lossless signal path, and flexible soundfield adjustment.
▼ Newly added 8GB built-in local music library for one-click import of music data for quick and easy access.
▼ 4 effects buses with 14 built-in effects: Echo, Reverb, Delay, Flanger, Hall Reverb, Room Reverb, Delay Reverb, Overdrive, Phaser, Pitch Shift, Tremolo, Limiter, Distortion, and Chorus, supporting flexible combination and application.
▼ Built-in five professional libraries: noise gate library, compressor library, EQ library, GEQ library, and effects library, enabling one-click recall for effortless sound shaping.
▼ Input channels feature a gain finder function for quickly locating the optimal gain level.
▼ 8 DCA groups and 6 mute groups.
▼ 15 custom function keys with assignable 15 functions for enhanced user operation convenience.
▼ Supports saving, recalling, importing, and exporting of scenes and effects libraries.
▼ Supports connection via LAN and external USB wireless WiFi module, enabling convenient web-based software control with simultaneous multi-device connectivity.
▼ Supports seamless switching between Chinese and English languages.
▼ Supports two-level panel lock to prevent accidental operation.
From the supplier
▼ 15.6-inch capacitive touch screen with 1920×1080 resolution, professional-grade display accuracy, precise fingertip control, and clear visual presentation.
▼ 13 dust-proof track-mounted motorized faders with 100mm travel for precise level control, offering smooth operation with no stepped feel.
▼ Total 22/26/34 physical signal inputs, including 20/24/32 XLR analog input channels with microphone preamps (featuring 8 COMBO jacks) and 1 stereo USB playback channel.
▼ Total 12/12/20 physical signal outputs, including 8/8/16 XLR analog output channels, 1 stereo TRS headphone monitor output, and 1 USB recording channel.
▼ Equipped with a selectable Bluetooth/audio card input module for convenient on-site audio playback from mobile phones or computers.
▼ 22 mixing buses, consisting of 14 mono buses, 4 effects buses, 2 mono MTRX matrix output buses, and 1 stereo main output bus.
▼ Input channels support 48V phantom power switching, analog gain, digital gain, phase inversion, 0–1000ms delay, pan/balance, level control, custom channel labeling, 5-band parametric EQ (switchable between parametric EQ, high shelf, low shelf, high-pass, and low-pass), noise gate, compressor, RTA, RTA freeze, and all-pass filter.
▼ Output channels support 0–1000ms delay, pan/balance, level control, custom channel labeling, 6-band parametric EQ (switchable between parametric EQ, high shelf, low shelf, high-pass, and low-pass), compressor, RTA, RTA freeze, and all-pass filter.
▼ Newly added channel freeze function for quickly locking the current RTA status of a channel, facilitating frequency response observation during complex live performances.
▼ Newly added channel all-pass filter function for precise phase control, lossless signal path, and flexible soundfield adjustment.
▼ Newly added 8GB built-in local music library for one-click import of music data for quick and easy access.
▼ 4 effects buses with 14 built-in effects: Echo, Reverb, Delay, Flanger, Hall Reverb, Room Reverb, Delay Reverb, Overdrive, Phaser, Pitch Shift, Tremolo, Limiter, Distortion, and Chorus, supporting flexible combination and application.
▼ Built-in five professional libraries: noise gate library, compressor library, EQ library, GEQ library, and effects library, enabling one-click recall for effortless sound shaping.
▼ Input channels feature a gain finder function for quickly locating the optimal gain level.
▼ 8 DCA groups and 6 mute groups.
▼ 15 custom function keys with assignable 15 functions for enhanced user operation convenience.
▼ Supports saving, recalling, importing, and exporting of scenes and effects libraries.
▼ Supports connection via LAN and external USB wireless WiFi module, enabling convenient web-based software control with simultaneous multi-device connectivity.
▼ Supports seamless switching between Chinese and English languages.
▼ Supports two-level panel lock to prevent accidental operation.
