From the supplier
The standard configuration
Technical parameters
1. Lift or lower the midplane at least 70°
2. Thigh plate lifting ≥25°
3. The minimum height of bed surface is 480mm
4. Bed lifting 480mm ~ 750mm
5. Tilt the bed 0-12° from front to back
Electrical parameters
1. Power connection: 220VAC,50/60Hz
2. Input power ≤450VA
3. Protection level IPX4
4. Security classification II
5. Electric shock protection class B application part
Product features
1. Lift the midplane
2. Thigh plate lifting
3. Back and leg linkage
4. Bed lifting
5. Tilt the bed from front to back
6. Backplane X-ray
7. Hands-only CPR
8. Backplane Angle indicator
9. Front and rear tilt Angle indication
10. Electric CPR
11. One-click chair
12. One-click out of bed
13. Function lock
14. Battery power display
15. Floor lighting
16. The patient had an emergency stop
17. Central brake
18. Infusion stand jack
19. Four corners for collision avoidance
The standard configuration
1. One motor control box
2. Push rod motor 4
3. One full-function controller
4. One handheld controller
5. 2 sets of guardrail controller
6. One battery
7. 1 floor lamp
8. 1 set of headboard and foot board
9. Blow molded guardrail (European standard) 1 set (4)
10. Center caster 3+1 (each)
11. 4 anti-collision wheels
12. 4 sockets for infusion stand
13. 4 drainage hooks
14. 6 fastening rings of binding belt
15. 1 shelf at the end of bed
16. 1 set of winding frame
17. 1 extension board
