CXH7 Panama Canal Steering Light
WAROM TECHNOLOGY INCORPORATED COMPANY
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
CXH7 Panama Canal Steering Light
WAROM TECHNOLOGY INCORPORATED COMPANYThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Materials: Copper-Free Aluminum
- Size: 114x114x200mm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Copper-Free Aluminum
- Size: 114x114x200mm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Copper-Free Aluminum |
|---|---|
| Size | 114x114x200mm |
| Color | Gray |
Product details
| Materials | Copper-Free Aluminum |
|---|---|
| Size | 114x114x200mm |
| Color | Gray |
From the supplier
◆ Application
◆ Suitable for vessels longer than 100m to pass through the narrow channel, such as the Panama Canal and St. Lawrence waterway for navigation at night, it is required to set the steering light, which is installed at the stem (foremast) and the blue light of the steering light could be seen clearly from the Funabashi along the center line. If it is blocked by the crane, the steering light should be installed on the left and right of the stem(foremast).
◆ Housing
◆Brass material
◆ Cover
◆ Lampshade is made of specific heat resistant glass
Technical parameters Conformity to standards IEC 60598, CCS standard Ambient temperature -40℃~+55℃ Light source LED module Lamp holder E27 Degree of protection IP66 Cable entry M25×1.5 gland, suitable for Φ10~Φ18mm cable Terminal 3x1.5~2.5mm2Selection table Type Specification Light source Color Weight(kg) CXH7 220V/8W LED module Blue 3
From the supplier
◆ Application
◆ Suitable for vessels longer than 100m to pass through the narrow channel, such as the Panama Canal and St. Lawrence waterway for navigation at night, it is required to set the steering light, which is installed at the stem (foremast) and the blue light of the steering light could be seen clearly from the Funabashi along the center line. If it is blocked by the crane, the steering light should be installed on the left and right of the stem(foremast).
◆ Housing
◆Brass material
◆ Cover
◆ Lampshade is made of specific heat resistant glass
Technical parameters Conformity to standards IEC 60598, CCS standard Ambient temperature -40℃~+55℃ Light source LED module Lamp holder E27 Degree of protection IP66 Cable entry M25×1.5 gland, suitable for Φ10~Φ18mm cable Terminal 3x1.5~2.5mm2Selection table Type Specification Light source Color Weight(kg) CXH7 220V/8W LED module Blue 3
