Detail information of products

WHOLE VIEW OF RUNDA FACTORY

RUNDA POWER is professional manufacturer of diesel generator set, located in Ningde city, Fujian province, has been producing the diesel genset for decades of years, is well-known manufacturer in China and owns 4 model standardized plants and covering 32000 square meters.

RUNDA POWER is OEM of CUMMINS, ISUZU, MITSUBISHI, STAMFORD, LEROY SOMER sound brands of engine and alternator, has strong and reliable business relations with CUMMINS, ISUZU, PERKINS, DEUTZ, KUBOTA, MITSUBISHI, YANMAR, the genset power ranging from 7kva to 3500kva.

DIESEL GENSET POWERED BY CUMMINS

CUMMINS Inc, is a global leading manufacturer of power equipment,who devoted to the engine R&D and fabricating.

CMMINS is organized around four business segments-Engine, Power generation, componets business and districution- and provides spare parts and services by more than 5000 authorised service agencies from more than 160 countries.

VARIOUS DESIGNS FOR CUMMINS ENGINE GENSETS FOR THE CHOICES ACCRODING TO DIFFERENT POWER

GENERATOR SET SUPPLY SCOPE

>100% original brand-new CUMMINS engine

>Beside RUNDA brand alterantor, Original Stamford, Leroy somer, Mecc Alte alterantor are available for the genset

> DATAKOM D300 controller as standard, Deep sea and ComAp, Smartgen brands controller are available

>Optional open type or silent type

>Standard generator set with 8hours, skid type baseframe with integral fuel tank.

>50ºC with copper wire radiator

>12V/24V DC battery charger, Battery, battery tray and cable.

>Rubber absorber for engine, radiator,alternator and control panel.

>Fan protection wire basket will be larger, thick and strong.

>DELIXI circuit breaker.

>All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load, 110% load and all protection function (overspeed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)


WE ARE CARE FOR EACH GENSET PRODUCTION

> The enclosure of generator coated by high quality polyester powder with 200 micron thickness( thicker than others with 100micron), which keeps the generator neither fading nor change for more than 10years, anti-corrision as well.

> Cold-rolled material rion sheet for canopy , which is better than hot-rolled one in harness, thoughness and extensibility.

> The iron plate, 2mm thickness for doors and other parts,and 4-6mm(depand on the power) thickness on the fuel tank, its better than others' 1.5mm.

> The radiator, 50degrees with copper material, big and strong one for the genset cooling and anti-vibration.

> The battery, SAIL brand battery, which is one of top brands in China with high quality and long lifetime.

> 4 pole circuit breaker insteads of 3pole to be electric leakage prtection.

> The soundproof sponge is covered by jean coloth, 40mm thickness sponge.

>LED lights installed inside of genset for checking the genset conveniently.

>High pressure fuel pipe for fuel inlet, good in seal, longer lifetime

>The switch for the fuel pipe with high quality one.

>Industrial silencer with big and strong one covered by portective material.

>Perfect outlet sheath seamless connection and wire harness protective cover.

>50 degrees big and strong radiator, best for the genset's cooling and anti-virbration.

CUMMINS ENGINE GENSET, THE POWER RANGING FROM 27KVA TO 3500KVA ARE AVAILABLE, SPECIFICATION AS BELOW,

GENSET PRIME POWER STANDBY POWER ENGINE ModelkwkvakwkvaBrand        Cylinder Model                   SPEED GOVERNOR M-C3022 27 24 30 DCEC4L4B3.9-G1MechM-C3022 27 24 30 DCEC4L4B3.9-G2ElecM-C4432 40 36 44 DCEC4L4BT3.9-G1MechM-C4432 40 36 44 DCEC4L4BT3.9-G2ElecM-C5540 50 44 55 DCEC4L4BTA3.9-G2ElecM-C6648 60 53 66 DCEC4L4BTA3.9-G2ElecM-C8663 78 69 86 DCEC4L4BTA3.9-G11ElecM-C10072 90 79 99 DCEC6L6BT5.9-G1MechM-C11080 100 88 110 DCEC6L6BT5.9-G2ElecM-C13296 120 106 132 DCEC6L6BTA5.9-G2ElecM-C150110 138 121 151 DCEC6L6BTAA5.9-G2ElecM-C180130 163 143 179 DCEC6L6BTAA5.9-G12ElecM-C200150 188 165 206 DCEC6L6CTA8.3-G1MechM-C200150 188 165 206 DCEC6L6CTA8.3-G2ElecM-C220160 200 176 220 DCEC6L6CTAA8.3-G2ElecM-C275200 250 220 275 DCEC6L6LTAA8.9-G2ElecM-C290210 263 231 289 DCEC6L6LTAA8.9-G3ElecM-C400288 360 320 400 DCEC6LQSZ13-G6ElecM-C413300 375 330 413 DCEC6L6ZTAA13-G3ElecM-C440320 400 352 440 DCEC6LQSZ13-G7ElecM-C480350 438 384 480 DCEC6L6ZTAA13-G2ElecM-C480350 438 384 480 DCEC6L6ZTAA13-G4ElecM-C480350 438 384 480 DCEC6LQSZ13-G2ElecM-C500360 450 400 500 DCEC6LQSZ13-G5ElecM-C550400 500 440 550 DCEC6LQSZ13-G3ElecM-C275200 250 220 275 CCEC6L MTA11-G2AElecM-C275200 250 220 275 CCEC6L MTA11-G2ElecM-C275200 250 220 275 CCEC6LNT855-GAElecM-C275200 250 220 275 CCEC6LNTA855-G1ElecM-C303220 275 242 303 CCEC6L NTA855-G1AElecM-C344250 313 275 344 CCEC6L MTAA11-G3ElecM-C344250 313 275 344 CCEC6LNTA855-G1BElecM-C344250 313 275 344 CCEC6LNTA855-G2ElecM-C378275 344 303 378 CCEC6L NTA855-G2AElecM-C385280 350 308 385 CCEC6L NTA855-G4ElecM-C413300 375 330 413 CCEC6L NTAA855-G7ElecM-C413300 375 330 413 CCEC6L KTA19-G2ElecM-C440320 400 352 440 CCEC6LQSNT-G3ElecM-C440320 400 352 440 CCEC6L NTAA855-G7AElecM-C500360 450 400 500 CCEC6L KTA19-G3ElecM-C550400 500 440 550 CCEC6L KTA19-G3AElecM-C550400 500 440 550 CCEC6LKTA19-G4ElecM-C578420 525 462 578 CCEC6LKTAA19-G5ElecM-C633460 575 506 633 CCEC6L KTAA19-G6ElecM-C650472 590 520 650 CCEC6LKTA19-G8ElecM-C715520 650 572 715 CCEC6L QSK19-G4ECMM-C688500 625 550 688 CCEC6L KTAA19-G6AElecM-C688500 625 550 688 CCECV12 KT38-GElecM-C788570 713 630 788 CCECV12 KT38-G1ElecM-C800580 725 640 800 CCECV12 KT38-GAElecM-C825600 750 660 825 CCECV12KTA38-G2ElecM-C880640 800 704 880 CCECV12 KTA38-G2BElecM-C1000728 910 800 1000 CCECV12KTA38-G2AElecM-C1100800 1000 880 1100 CCECV12KTA38-G5ElecM-C1250900 1125 1000 1250 CCECV12KTA38-G9ElecM-C13751000 1250 1100 1375 CCECV12QSK38-G5ElecM-C13751000 1250 1100 1375 CCECV16 KTA50-G3ElecM-C15131100 1375 1210 1513 CCECV16 KTA50-G8ElecM-C16501200 1500 1320 1650 CCECV16 KTA50-GS8Elec
