CS series big flow centrifugal pump
- FOB goods (100)
- $8,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $280
- Section 301 tariff (25.0%)
- $2,000
- Customs fees (MPF/HMF)
- $43
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
CS series big flow centrifugal pump
- FOB goods (100)
- $8,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $280
- Section 301 tariff (25.0%)
- $2,000
- Customs fees (MPF/HMF)
- $43
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: Cast Iron
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
- Made in: Fujian, China
About this product
- Materials: Cast Iron
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
- Made in: Fujian, China
Product details
| Materials | Cast Iron |
|---|
From the supplier
CS SERIES CENTRIFUGAL PUMP
Construction Features
PUMP
Pump Body: Cast iron
Impeller: PPO/ Brass / Stainless steel
Mechanical Seal: Ceramic steatite/metalized carbon
MOTOR
Single phase
Duty: Continuously rated
Motor Housing: Aluminum
Shaft: 45# steel / Stainless steel
Motor. Closed, externally ventilated
Insulation Class: B/F
Protection Class: IP44 /IP54
Applications and Installation
The CS series are specifically designed to achieve high delivery with low to medium heads for industrial and agricultural uses. Their volute impeller makes it able to pump water that is even fairly dirty.
High delivery rates under continuous or heavy duty, making them advantageous for rain and gravity irrigation, for pumping water from lakes, river, well and for a wide variety of other applications, etc.
Their cast iron pump body, aluminum housing and brass impeller ensure reliable quality and very popular with users
Operating Conditions
Max. ambient temperature up to 40°C
Max. fluid temperature up to 40°C
Max. working pressure up to10 bar
Technical Data
Model Single-phase motor n=2850r/min Q m3/h 0 6 12 18 24 30 36 42 48 54 60 Inputmax Output power Current Q.max H.max Suct max L/min 0 100 200 300 400 500 600 700 800 900 1000 kW kW HP A L/min m m CS150 1.8 1.1 1.5 8.3 600 15 9 H meter 15 15 14.5 13.5 12.5 10.5 8 CS200 2.1 1.5 2 9.5 800 15 15 15 14.5 13.8 13 12.5 11 9.5 8 CS250 2.1 1.5 2 9.6 800 15 15 15 14.5 13.8 13 12.5 11 9.5 8 CS300 2.3 2.2 3 10.2 1000 16 16 16 15.5 15.2 14. 14 13 12 10.5 9 7
SANHE ELECTRICAL (FUJIAN) CO., LTD. is a professional designer and manufacturer of water pumps and electric motors in Fuan, Fujian, China. It is subsidiary of Mindong Group which was founded in 1958.
Our main products are water pumps, electric motors and alternators, which are 50 series over 1000 varieties export to more than 60 countries and areas.
Years of manufacturing development, we are willing to work with global customers and partners to create a brighter future together.
FAQ
1. Q: What is your MOQ of this item?
A: 100PCS
2. Q: Are you Trade Company or Manufacturer?
A: Manufacturer, we are a professional designer and manufacturer of water pumps and electric motors.
3. Q: Is customized service available?
A: Sure, OEM & ODM both are available.
4. Q: How long is your warranty?
A: 14 months
5. Q: What is the delivery time?
A: 30 days after receiving orginal L/C or deposit by TT.
About the supplier
Main products: Electric pump,AC motor,Other Motor and Accessories,Other Motor,Motor remote control,Generating Sets,AC synchronous brushless alternator
- βExhibited at 10 of the last 10 Canton Fairs
- βManufacturer
- βFounded 2003
- βBrand exhibitor
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 2003
- Brand exhibitor
