About this product
- Materials: BC, TC ,PVC
- Size: 100m
- Color: gray
- Support network: Other
- Usage: Other
- Certification: Other
- Exports to: Mainland China, Southeast Asia, Other European Countries
About this product
- Materials: BC, TC ,PVC
- Size: 100m
- Color: gray
- Support network: Other
- Usage: Other
- Certification: Other
- Exports to: Mainland China, Southeast Asia, Other European Countries
Product details
| Materials | BC, TC ,PVC |
|---|---|
| Size | 100m |
| Color | gray |
| Support network | Other |
| Usage | Other |
| Certification | Other |
Product details
| Materials | BC, TC ,PVC |
|---|---|
| Size | 100m |
| Color | gray |
| Support network | Other |
| Usage | Other |
| Certification | Other |
From the supplier
Description
Electronic, 2 Conductor 16AWG (7x24) Bare Copper, PVC Insulation, Overall Foil Shield, Black PVC
Outer Jacket
Construction
1 Conductor 7*0 51mm(24AWG) BC (Bare Copper)
2.Insulation 2.3mm PVC (Polyvinyl Chloride), 1Pair (Black, White)
3.Outer Shield Bi-Laminate (Alum+Poly) 100% Tape
7x0.40mm(26AWG)TC Drainwire
4.Outer Jacket 6.7mm PVC (Polyvinyl Chloride) with Ripcord
Electronical Characteristics
Nom. Conductor DC 13.8 Ohm/km
Nom. Capacitance (Cond-to-Cond) 200 pF/m
Nom. Capacitance (Cond-to-Other) 374 pF/m
Max. Current 11 Amps per Conductor at 30°C
Nom Outer Shield DC 16.8 Ohm/km
Voltage 300V
Mechanical Characteristics
Bending Radius 66mm
Max. Pull Tension 18kg
Bulk Cable Weight 59 kg/km
From the supplier
Description
Electronic, 2 Conductor 16AWG (7x24) Bare Copper, PVC Insulation, Overall Foil Shield, Black PVC
Outer Jacket
Construction
1 Conductor 7*0 51mm(24AWG) BC (Bare Copper)
2.Insulation 2.3mm PVC (Polyvinyl Chloride), 1Pair (Black, White)
3.Outer Shield Bi-Laminate (Alum+Poly) 100% Tape
7x0.40mm(26AWG)TC Drainwire
4.Outer Jacket 6.7mm PVC (Polyvinyl Chloride) with Ripcord
Electronical Characteristics
Nom. Conductor DC 13.8 Ohm/km
Nom. Capacitance (Cond-to-Cond) 200 pF/m
Nom. Capacitance (Cond-to-Other) 374 pF/m
Max. Current 11 Amps per Conductor at 30°C
Nom Outer Shield DC 16.8 Ohm/km
Voltage 300V
Mechanical Characteristics
Bending Radius 66mm
Max. Pull Tension 18kg
Bulk Cable Weight 59 kg/km
