200TPD Millet Processing Machine Millet Milling Machine

　　Millet processing machine refers to the millet processing plant, which consists of the following sections: millet cleaning, hulling, husk and millet separation, milling (peeling, whitening, polishing), color sorting and packaging.

　　200TPD Millet Processing Machine Millet Milling Machine Technology Flow:

　　Millet cleaning---stoner---hulling mill---grading sieve---peeling off------polishing---grading---color sorting---packing.

　　1. Bucket Elevator is mainly used to transport millet in complete processing line.

　　2. Vibrating screen is specially used for separating the impurities from millet.

　　3. After cleaning, millet will be transported into Proportion Stoner machine to separate the stone from the millet.

　　4. Next, the millet into the Hulling Machine to remove the shell.It can separate the shell from the paddy husk mixture through the suction effect.

　　5. The millet that has removed the shell will be into the Iron Polishing Machine.The machine is mainly used for cleaning the millet to make them look brightly. It is one of the key processing millet.

　　6. Suction Separator will separate the low gravity impurities(such as hull, dust etc.) from the millet.

　　7. Out from the suction separator ,the millet into the Color Sorter to get more high quality millet, white millet and break millet will be passed.

　　8. Last, high quality millet we need will be packed through the Automatic Packaging Scales.

　　Main production index:

　　1. Production capacity: 20-500t millet/24hours

　　2. Products structure and yield rate: net millet yield rate: 70-75%;damage rate：1%;skin and husk rate：25-30%

　　Millet processing plant processing capacity: 20t-500t

　　Technical Parameter:

Project/Model number

5T machine

10T machine

20T machine

30T machine

Production(T/D)

5

10

20

30

Power(kw)

19

47.9

59.15

72.05

Project/Model number

50T machine

80T machine

100T machine

200T machine

Production(T/D)

50

80

100

200

Power(kw)

101.65

144.6

164.8

296
