Two major types of crosslinked PE foam are:

1.Irriadiated crosslinked polyethylene foam(IXPE FOAM) is very fine celled microcellular foam. Iriadiated crosslinked foam is used for medical applications, heart forming, and high end protective packaging and consumer products. This foam can actually be printed on very clearly.



2.Chemically crosslinked polyethylene foam(XPE FOAM) also has good physical properties, but has a larger more random cell structure. Chemically crosslinked foam can also be used for packaging, heat forming and a large variety of applications.

1)Features:

1. Light weight, good elasticity

2. Weatherproof and waterproof

3. Flame retardant

4. Sound absorption

5. Heat insulation

6. Thermal insulation

7. Elastic and flexibility



2).Advantages

 IXPE/XPE Crosslinked Polyethylene Foamed Sheet/Expanded Foam Sheets

1. Heat Insulation:

Singlefoaming structure can reduce the loss of heat between air convections, suitable for making heat preservation pipes and boards. Good anti-dew capability, suitable for humid environments like refrigerators, air-conditioners and ice houses, etc.

2. Cushion Capability: Semi-hard quality foams have good rebound capabilities after strong impact, suitable for the packing of instruments, semi-conductors and electronics, etc.

3. Sound Absorption:

 Good sound and noise absorption capability, suitable for sound absorption and insulation parts of automobiles, electro-motors and other equipment and environments with loud noises.

4. Shaping Capability:

Good heat endurance and ductility capability with even density, suitable for making deep interior parts like shaping in vacuum and hot environments, like the air conditioning vaporizing tank of automobiles, hot-shaped peak canopy of vehicles and shoes, etc.

5.Good chemical, oil, acid and alkali durability capabilities.

It is safe and odorless, easy for machining and casting, and can be mixed with many other materials. It has a wide developing area as a new environmentally-safe material.

3)Technical Index

Density200±30125±15100±1066.7±850±640±433.3±3Hardness60-7050-6045-5035-4530-352-3018-25Water absorption≤0.02≤0.02≤0.03≤0.03≤0.04≤0.04≤0.05(23°C 24h)g/cm³Thermal conductivity≤0.092≤0.082≤0.07≤0.062≤0.053≤0.047≤0.041Tensile strength(mpa)L≥1.35≥1.12≥0.88≥0.68≥0.39≥0.33≥0.25 M≥1.08≥0.89≥0.71≥0.56≥0.33≥0.25≥0.20TesibilityL≥260≥230≥210≥190≥170≥160≥140 M≥220≥200≥185≥170≥150≥135≥130Tearing strengthL≥5.90≥4.80≥3.60≥2.80≥1.80≥1.60≥1.35

4) Applications



Packagingelectronics, components, appliances and other demanding protection and packaging materialsVehicleautomotive interior decoration, ceiling, dashboard, cover the old boards, coolers, flooring and other materials.Culture/sports,school teaching materials, children's toys, sporting a variety of mattress, surfboard, swimming with life jackets, float and cushioning materials; kitchen sink mat, bath cap and slippers, hats InsulationsHeating and cooling machines, tanks, reservoirs and insulation materials; central air conditioning, air conditioning with heat insulation, Sound proof,sound-absorbing,ConstructionConstruction, civil engineering field, roof, wall insulation, thermal insulation, cushioning, anti-condensation, waterproof, leak-proof,  wallpaper,anti-corrosion materials; various infrastructure construction materials; anti-frost, shock cushioning material; interior decoration,  mattress materials,wall sound barriers
