Chang Yao,Fully automatic vacuum pressure defoaming oven\CYAP-65V\CYAP-65V-2
SUMEC INTERNATIONAL TECHNOLOGY CO.,LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Chang Yao,Fully automatic vacuum pressure defoaming oven\CYAP-65V\CYAP-65V-2
SUMEC INTERNATIONAL TECHNOLOGY CO.,LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Size: ·
- Color: ·
- Customized: Non-CustomizedCustomized
- Power supply: BatteryOther
- Imaging type: Real-ImageOther
- Application: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Size: ·
- Color: ·
- Customized: Non-CustomizedCustomized
- Power supply: BatteryOther
- Imaging type: Real-ImageOther
- Application: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Size | · |
|---|---|
| Color | · |
| Customized | Non-CustomizedCustomized |
| Power supply | BatteryOther |
| Imaging type | Real-ImageOther |
| Application | Other |
Product details
| Size | · |
|---|---|
| Color | · |
| Customized | Non-CustomizedCustomized |
| Power supply | BatteryOther |
| Imaging type | Real-ImageOther |
| Application | Other |
From the supplier
technical parameters
Inner size: W465 *D571*H354(inner diameter: Φ 650mm)
Power supply: AC380V 3φ 50Hz 15kw
Material: Internal material/Internal material: SUS304#
External material/External material: SUS304#
Temperature range: RT~200℃
Pressure range: 50torr~8kg/cm²
Booster module: 1
Pressure control accuracy: ±0.1kg
Oxygen content: ≤50ppm
Alignment function: Pre-Aligner-(Automatic alignment)
Robot: Robot-(Automatic loading and unloading/Automatic loading and unloading)
S/W：PLC Base/PC Contorl
Industrial PC system: Win7 / Win10 interface/screen: Chinese/Eng
Supported by: SECS/GEM
Temperature detection: Six-point temperature detection, real-time display and historical data copied out and backed up
CDA: 5~8kg/cm² Minimum flow/Minimum flow: 400L/min
N2：Φ10mm 5kg/cm²
Cooling system: Cooling rate/Cooling rate: 1~5℃/min (unloaded) Cooling water/Cooling water: 17~23℃ 25L/min
Safety devices: over-temperature protection, motor overload protection, overpressure protection, bore door self-locking device, bore door detection device, leakage protection, abnormal air pressure alarm, abnormal water pressure alarm
From the supplier
technical parameters
Inner size: W465 *D571*H354(inner diameter: Φ 650mm)
Power supply: AC380V 3φ 50Hz 15kw
Material: Internal material/Internal material: SUS304#
External material/External material: SUS304#
Temperature range: RT~200℃
Pressure range: 50torr~8kg/cm²
Booster module: 1
Pressure control accuracy: ±0.1kg
Oxygen content: ≤50ppm
Alignment function: Pre-Aligner-(Automatic alignment)
Robot: Robot-(Automatic loading and unloading/Automatic loading and unloading)
S/W：PLC Base/PC Contorl
Industrial PC system: Win7 / Win10 interface/screen: Chinese/Eng
Supported by: SECS/GEM
Temperature detection: Six-point temperature detection, real-time display and historical data copied out and backed up
CDA: 5~8kg/cm² Minimum flow/Minimum flow: 400L/min
N2：Φ10mm 5kg/cm²
Cooling system: Cooling rate/Cooling rate: 1~5℃/min (unloaded) Cooling water/Cooling water: 17~23℃ 25L/min
Safety devices: over-temperature protection, motor overload protection, overpressure protection, bore door self-locking device, bore door detection device, leakage protection, abnormal air pressure alarm, abnormal water pressure alarm
