Specification : 0.08mm-25.00mm

CCS wire use the cladding or plating craft to make copper around the steel coil to create atom

bonds between the two metals, it can be process like a single metal, when pulling out, annealing,

drawing the copper and steel proportion to the diameter changes, but copper layer remains the

same. Due to the high frequency signal has a "hasten skin effect" characteristic, therefore copper

coated aluminum wire and copper clad steel wire in the high frequency signal transmission ( more than 5MHz). The conductivity is the same as pure copper wire.

Normal Package:

Spool size

DIN 100, DIN 130, DIN 180, DIN 250; DIN 400, DIN500, DIN630, DIN800;

Application:

1. Coaxial cable inner conductor of the cable TVsubscriber line and near the family line;
2. Computer LAN, access network, cable, field cableconductor material;
3. A variety of electronic components of the connector;overhead line of the power ;transmission and telephonelines:
4. Electrified rail, rail transit lines catenary overhead lines;
5. Textile shielding of the power cable line; electric powerindustry grounding rods; medical devices and equipment cable conductor material;
6. High temperature electronic conductor material;
7. High temperature RF cable core wire;
8. Hig h-frequency sig nal transmission;
9. The preferred cable TV coaxial cable conductor;
