Product Description Produtct description
Lutai fiber cement board is a new type of green environmental protection board with excellent performance, such as fireproof, moisture proof,insect-resistant ant, easy working, thermal insulation,low deformation coefficient and durable.





Product Parameters Material cement,quartz sand ,pulp and others Fireproof rater A1 class incombustible(GB8624-2012) Density >1.4g/cm3 Water content ratio ≤10% Swelling ratio ≤0.25% Shrinking ratio ≤0.5% Anti-bending strength ≥16MPA Impact strength ≥2.0KJ/M2 Frost resistence No cracking and delamination after 100 cycles freezing and thawiing Thickness 12-20mm Size 200*2400mm, 400*2400mm,and others



Product characteristics

Advantages:

1.Easy to install

2.Structural waterproofing function

3.Both internal and external walls are acceptable

4.Not affected by floor height or total building height

5.Both horizontal and vertical installation are acceptable


Installation steps

Step 1
Install the starting part and fix it with screws or nails.
Step 2
Install the first board, insert the female mouth of the board into the starting part
Step 3
Install the second board.
The female port of the second board is aligned with the sub port of the first board and inserted tightly downward to ensure tight connection. Install the third and fourth boards in the same way..., Until the installation is completed.



Installation rendering
