CA024 Ceiling speaker system 5W Best Roof In wall ceiling loudspeaker ceiling sound system speakers
Guangzhou Shengxun Electronic Technology Co., Ltd.1/10 fairsManufacturerModel CA024L
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
CA024 Ceiling speaker system 5W Best Roof In wall ceiling loudspeaker ceiling sound system speakers
Guangzhou Shengxun Electronic Technology Co., Ltd.1/10 fairsManufacturerModel CA024L
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: ABS
- Size: 70×Φ186mm
- Color: White
- Application: Other
- Style: Wired
- Weight: 0.6kg
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: ABS
- Size: 70×Φ186mm
- Color: White
- Application: Other
- Style: Wired
- Weight: 0.6kg
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | ABS |
|---|---|
| Size | 70×Φ186mm |
| Color | White |
| Application | Other |
| Style | Wired |
| Weight | 0.6kg |
Product details
| Materials | ABS |
|---|---|
| Size | 70×Φ186mm |
| Color | White |
| Application | Other |
| Style | Wired |
| Weight | 0.6kg |
From the supplier
Specifications
Model
CA024L
Rated power
5W
Impedance
8 Ohms
Frequency response
140Hz-18kHz
Sensitivity
93±2dB
Maximum Sound Pressure Level
98±2dB
Speaker unit6
6.5" speaker *1
Hole cutout size
165-170mm/6.50Inch-6.69Inch
Product overall size
186mm/7.32Inch
Product mounting depth
70mm/2.76Inch
Step3: Flip up the spring clips on both sides of the speaker and insert them into the mounting holes. Then release your hand and gently push the speaker to embed it into the ceiling (see the figure below). To avoid being injured by the spring clips, it is recommended to wear work gloves when performing this operation.
Installation Steps:
Step1: Cut the Speaker Hole to 165-170mm/6.50Inch-6.69Inch.
Step2: Wire the Speaker. (Blue/White wire: positive pole Red wire: negative pole)Step3: Flip up the spring clips on both sides of the speaker and insert them into the mounting holes. Then release your hand and gently push the speaker to embed it into the ceiling (see the figure below). To avoid being injured by the spring clips, it is recommended to wear work gloves when performing this operation.
From the supplier
Specifications
Model
CA024L
Rated power
5W
Impedance
8 Ohms
Frequency response
140Hz-18kHz
Sensitivity
93±2dB
Maximum Sound Pressure Level
98±2dB
Speaker unit6
6.5" speaker *1
Hole cutout size
165-170mm/6.50Inch-6.69Inch
Product overall size
186mm/7.32Inch
Product mounting depth
70mm/2.76Inch
Step3: Flip up the spring clips on both sides of the speaker and insert them into the mounting holes. Then release your hand and gently push the speaker to embed it into the ceiling (see the figure below). To avoid being injured by the spring clips, it is recommended to wear work gloves when performing this operation.
Installation Steps:
Step1: Cut the Speaker Hole to 165-170mm/6.50Inch-6.69Inch.
Step2: Wire the Speaker. (Blue/White wire: positive pole Red wire: negative pole)Step3: Flip up the spring clips on both sides of the speaker and insert them into the mounting holes. Then release your hand and gently push the speaker to embed it into the ceiling (see the figure below). To avoid being injured by the spring clips, it is recommended to wear work gloves when performing this operation.
