BDD91 SeriesExplosion-proof Light Fittings
WAROM TECHNOLOGY INCORPORATED COMPANY
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
BDD91 SeriesExplosion-proof Light Fittings
WAROM TECHNOLOGY INCORPORATED COMPANYThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Copper-free Aluminium Alloy
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Copper-free Aluminium Alloy
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Copper-free Aluminium Alloy |
|---|---|
| Color | Yellow |
Product details
| Materials | Copper-free Aluminium Alloy |
|---|---|
| Color | Yellow |
From the supplier
◆ Explosion Protection to
EN, IEC
◆ Can be used in
Zone 1,2,21,22
Class I
Division 1
Groups A, B, C, D
◆ Applicable lamp(max.400W):
-Metal halide lamp (HIE)
-High pressure sodium lamp(HSE)
-High pressure mercury lamp(HME)
◆ Three enclosure types:150,250,400.
◆ Integral control gear,easy installation and maintenance
Global (IECEx) IECEx CQM 12.0016X Gas and dustEx d IIC T□1）Gb
Ex t IIIC T□1）Db IP66
Europe (ATEX) DNV 11 ATEX 05977X Gas and dust II 2 G Ex d IIC T□1）Gb II 2 D Ex tb IIIC T□1）Db IP66 Certificates IECEx; ATEX；CU-TR Conformity to standards EN; IEC Degree of protection IP66/IP67 Ambient temperature -60℃~+55℃ MaterialCopper-free Aluminium Alloy,powder coated surface,yellow (RAL1021),
Toughened glass,stands 4J impact
Weight 11.2~16.7kg Dimensions different power has different dimension Lamp specification HIE HSE HME Lamp power (W) 70~400W Rated voltage 220~240V AC 50/60Hz Rated luminous flux 3800~56500lm Terminal 3 x 1.5~4mm㎡ (L+N+PE) Cable entries 2/1 Cable gland（optional） DQM-II(Ex d）or DQM-III(Ex d） is recommended.
From the supplier
◆ Explosion Protection to
EN, IEC
◆ Can be used in
Zone 1,2,21,22
Class I
Division 1
Groups A, B, C, D
◆ Applicable lamp(max.400W):
-Metal halide lamp (HIE)
-High pressure sodium lamp(HSE)
-High pressure mercury lamp(HME)
◆ Three enclosure types:150,250,400.
◆ Integral control gear,easy installation and maintenance
Global (IECEx) IECEx CQM 12.0016X Gas and dustEx d IIC T□1）Gb
Ex t IIIC T□1）Db IP66
Europe (ATEX) DNV 11 ATEX 05977X Gas and dust II 2 G Ex d IIC T□1）Gb II 2 D Ex tb IIIC T□1）Db IP66 Certificates IECEx; ATEX；CU-TR Conformity to standards EN; IEC Degree of protection IP66/IP67 Ambient temperature -60℃~+55℃ MaterialCopper-free Aluminium Alloy,powder coated surface,yellow (RAL1021),
Toughened glass,stands 4J impact
Weight 11.2~16.7kg Dimensions different power has different dimension Lamp specification HIE HSE HME Lamp power (W) 70~400W Rated voltage 220~240V AC 50/60Hz Rated luminous flux 3800~56500lm Terminal 3 x 1.5~4mm㎡ (L+N+PE) Cable entries 2/1 Cable gland（optional） DQM-II(Ex d）or DQM-III(Ex d） is recommended.
