AYA Torx Countersunk Self Tapping Screws
AYA Fasteners (Hebei) Co., Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
AYA Torx Countersunk Self Tapping Screws
AYA Fasteners (Hebei) Co., Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Carbon Steel
- Size: Full Size Available
- Color: Sliver, Black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Carbon Steel
- Size: Full Size Available
- Color: Sliver, Black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Carbon Steel |
|---|---|
| Size | Full Size Available |
| Color | Sliver, Black |
Product details
| Materials | Carbon Steel |
|---|---|
| Size | Full Size Available |
| Color | Sliver, Black |
From the supplier
As a global supplier of customized fastening solutions, AYA's senvice process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.
PRODUCT DESCRIPTION
Commodity: AYA Torx Countersunk Self Tapping Screws
Brand: AYA®
Standard: JIS B 1128 (F)
Alternative Standard: ISO,DIN,ASME,ANSI,JIS,GB,NON-STANDARD CUSTOMIZATION
Thread Type: Self-Tapping Screw Thread
Material: Carbon Steel
Property Class: A
Form/Shape Of Tip: C
Diameter: Full-Size Available
Finish: Plain, Black Oxide, Zinc Plated, Hot Dipped Galvanized, Oxidation, Dacromet, Phosphating, Cadmium Electroplate, Nickel Plated
Head Type: Countersunk Head / Flat Head
Drive Type: Cross Drive
MOQ: 1000kgs
Lead Time: 30 to 60 days
DIMENSION TABLES
Nominal Diameterd ST2.9 ST3.5 ST4.2 ST4.8 ST5.5 ST6.3 P Pitch 1.1 1.3 1.4 1.6 1.8 1.8 a 1.1 1.3 1.4 1.6 1.8 1.8 dk max Theory 6.3 8.2 9.4 10.4 11.5 12.6 Actual 5.5 7.3 8.4 9.3 10.3 11.3 min 5.2 6.9 8 8.9 9.9 10.9 k max 1.7 2.35 2.6 2.8 3 3.15 r max 1.2 1.4 1.6 2 2.2 2.4 y Ref. Type C 2.6 3.2 3.7 4.3 5 6 Type F 2.1 2.5 2.8 3.2 3.6 3.6 Type R / 2.7 3.2 3.6 4.3 5 Socket No. 10 15 20 25 25 30 A Ref. 2.8 3.35 3.95 4.5 4.5 5.6 t max 0.91 1.3 1.58 1.78 2.03 2.42 min 0.65 1 1.14 1.39 1.65 2.02
PRODUCT DETAILS
PRODUCT ADVANTAGES
ADVANTAGES OF TORX COUNTERSUNK SCREWS
1. Torx countersunk screws are corrosion-resistant and strong.
2. High-quality metal self-tapping screws with sharp, clean, and accurate threads and tips make it easy to install into metal.
3. Their flat and countersunk head and the tapered area sink into the objects and surface and rest flush in materials.
4. It hides the fixtures and helps maintain the integrity of the metal.
5. They are also valuable in woodworking because they prevent splitting, cracking, and gouging.
6. AYA strictly follows international standards during production and constantly works on productive technology to meet the market and customers' requirements.
7. AYA has a sophisticated supply-chain system, integrated warehouse management system, and quick responsive logistic system.
QUALITY INSPECTION
1. The QC inspectors are well experienced in product knowledge as well as manufacturing techniques. Special instruments are applied to conduct multiple tests to ensure that the final products could meet the requirements of the market and customers.
2. Experienced QC staff can provide customers with accurate quality inspection reports.
3. Final product inspection is a key point. AYA has a complete sampling check system for this important task and each detail will be fully inspected.
PACKAGING & CONTAINER LOADING
1. Mature warehousing and logistics systems and digital tools make the goods delivery highly efficient.
2. Automated packing lines improve the quality and speed of the packaging work.
3. AYA has always attached great importance to the R&D of the packaging to improve the appearance as well as the durability in the process of shipment.
4. Packaging is important for product preservation as well as safety. AYA has constantly developed new solutions to keep products intact during the shipment process.
USAGE SCENARIOS
Contact AYA
From the supplier
As a global supplier of customized fastening solutions, AYA's senvice process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.
PRODUCT DESCRIPTION
Commodity: AYA Torx Countersunk Self Tapping Screws
Brand: AYA®
Standard: JIS B 1128 (F)
Alternative Standard: ISO,DIN,ASME,ANSI,JIS,GB,NON-STANDARD CUSTOMIZATION
Thread Type: Self-Tapping Screw Thread
Material: Carbon Steel
Property Class: A
Form/Shape Of Tip: C
Diameter: Full-Size Available
Finish: Plain, Black Oxide, Zinc Plated, Hot Dipped Galvanized, Oxidation, Dacromet, Phosphating, Cadmium Electroplate, Nickel Plated
Head Type: Countersunk Head / Flat Head
Drive Type: Cross Drive
MOQ: 1000kgs
Lead Time: 30 to 60 days
DIMENSION TABLES
Nominal Diameterd ST2.9 ST3.5 ST4.2 ST4.8 ST5.5 ST6.3 P Pitch 1.1 1.3 1.4 1.6 1.8 1.8 a 1.1 1.3 1.4 1.6 1.8 1.8 dk max Theory 6.3 8.2 9.4 10.4 11.5 12.6 Actual 5.5 7.3 8.4 9.3 10.3 11.3 min 5.2 6.9 8 8.9 9.9 10.9 k max 1.7 2.35 2.6 2.8 3 3.15 r max 1.2 1.4 1.6 2 2.2 2.4 y Ref. Type C 2.6 3.2 3.7 4.3 5 6 Type F 2.1 2.5 2.8 3.2 3.6 3.6 Type R / 2.7 3.2 3.6 4.3 5 Socket No. 10 15 20 25 25 30 A Ref. 2.8 3.35 3.95 4.5 4.5 5.6 t max 0.91 1.3 1.58 1.78 2.03 2.42 min 0.65 1 1.14 1.39 1.65 2.02
PRODUCT DETAILS
PRODUCT ADVANTAGES
ADVANTAGES OF TORX COUNTERSUNK SCREWS
1. Torx countersunk screws are corrosion-resistant and strong.
2. High-quality metal self-tapping screws with sharp, clean, and accurate threads and tips make it easy to install into metal.
3. Their flat and countersunk head and the tapered area sink into the objects and surface and rest flush in materials.
4. It hides the fixtures and helps maintain the integrity of the metal.
5. They are also valuable in woodworking because they prevent splitting, cracking, and gouging.
6. AYA strictly follows international standards during production and constantly works on productive technology to meet the market and customers' requirements.
7. AYA has a sophisticated supply-chain system, integrated warehouse management system, and quick responsive logistic system.
QUALITY INSPECTION
1. The QC inspectors are well experienced in product knowledge as well as manufacturing techniques. Special instruments are applied to conduct multiple tests to ensure that the final products could meet the requirements of the market and customers.
2. Experienced QC staff can provide customers with accurate quality inspection reports.
3. Final product inspection is a key point. AYA has a complete sampling check system for this important task and each detail will be fully inspected.
PACKAGING & CONTAINER LOADING
1. Mature warehousing and logistics systems and digital tools make the goods delivery highly efficient.
2. Automated packing lines improve the quality and speed of the packaging work.
3. AYA has always attached great importance to the R&D of the packaging to improve the appearance as well as the durability in the process of shipment.
4. Packaging is important for product preservation as well as safety. AYA has constantly developed new solutions to keep products intact during the shipment process.
USAGE SCENARIOS
Contact AYA
