AYA Countersunk Chipboard Screws
AYA Fasteners (Hebei) Co., Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
AYA Countersunk Chipboard Screws
AYA Fasteners (Hebei) Co., Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Carbon Steel
- Size: Full Size Available
- Color: Sliver, Black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Carbon Steel
- Size: Full Size Available
- Color: Sliver, Black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Carbon Steel |
|---|---|
| Size | Full Size Available |
| Color | Sliver, Black |
Product details
| Materials | Carbon Steel |
|---|---|
| Size | Full Size Available |
| Color | Sliver, Black |
From the supplier
As a global supplier of customized fastening solutions, AYA's senvice process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.
PRODUCT DESCRIPTION
Commodity: AYA Countersunk Chipboard Screws
Brand: AYA®
Standard: DIN 7505 (A)
Alternative Standard: ISO,DIN,ASME,ANSI,JIS,GB,NON-STANDARD CUSTOMIZATION
Thread Type: Plastic Thread
Material: Carbon Steel
Form: A
Diameter: Full-Size Available
Finish: Plain, Black Oxide, Bright, Zinc Plated, Passivated
Head Type: Countersunk Head
Drive Type: PZ Drive
MOQ: 1000kgs
Lead Time: 30 to 60 days
DIMENSION TABLES
SPECIFICATIONS D 2.5 3 3.5 4 4.5 5 6 D max 2.5 3 3.5 4 4.5 5 6 min 2.25 2.75 3.2 3.7 4.2 4.7 5.7 P Pitch(±10%) 1.1 1.35 1.6 1.8 2 2.2 2.6 A max 2.1 2.35 2.6 2.8 3 3.2 3.6 DK max=nominal size 5 6 7 8 9 10 12 min 4.7 5.7 6.64 7.64 8.64 9.64 11.57 K 1.4 1.8 2 2.35 2.55 2.85 3.35 DP max=nominal size 1.5 1.9 2.15 2.5 2.7 3 3.7 min 1.1 1.5 1.67 2.02 2.22 2.52 3.22 SOCKET NO. 1 1 2 2 2 2 3 M 2.51 3 4 4.4 4.8 5.3 6.6
PRODUCT DETAILS
PRODUCT ADVANTAGES
ADVANTAGES OF COUNTERSUNK CHIPBOARD SCREWS
1. Countersunk chipboard screws can be used when doing general DIY work with particleboard and other softer types of wood.
2. When driven with chipboard screws, the top material is threaded in place.
3. Great for attaching hinges to kitchen cabinets and doors, as galvanizing helps the screws blend in with the hinges.
4. On csk chipboard screws, the threads run all the way down the length of the screw to the underside of the head. This makes the screws especially useful in situations where a super-holding force is required.
5. AYA relies on advanced equipment and professionals to produce fiberboard nails to ensure quality.
QUALITY INSPECTION
1. The QC inspectors are well experienced in product knowledge as well as manufacturing techniques. Special instruments are applied to conduct multiple tests to ensure that the final products could meet the requirements of the market and customers.
2. Experienced QC staff can provide customers with accurate quality inspection reports.
3. Final product inspection is a key point. AYA has a complete sampling check system for this important task and each detail will be fully inspected.
PACKAGING & CONTAINER LOADING
1. Mature warehousing and logistics systems and digital tools make the goods delivery highly efficient.
2. Automated packing lines improve the quality and speed of the packaging work.
3. AYA has always attached great importance to the R&D of the packaging to improve the appearance as well as the durability in the process of shipment.
4. Packaging is important for product preservation as well as safety. AYA has constantly developed new solutions to keep products intact during the shipment process.
USAGE SCENARIOS
Contact AYA
From the supplier
As a global supplier of customized fastening solutions, AYA's senvice process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.
PRODUCT DESCRIPTION
Commodity: AYA Countersunk Chipboard Screws
Brand: AYA®
Standard: DIN 7505 (A)
Alternative Standard: ISO,DIN,ASME,ANSI,JIS,GB,NON-STANDARD CUSTOMIZATION
Thread Type: Plastic Thread
Material: Carbon Steel
Form: A
Diameter: Full-Size Available
Finish: Plain, Black Oxide, Bright, Zinc Plated, Passivated
Head Type: Countersunk Head
Drive Type: PZ Drive
MOQ: 1000kgs
Lead Time: 30 to 60 days
DIMENSION TABLES
SPECIFICATIONS D 2.5 3 3.5 4 4.5 5 6 D max 2.5 3 3.5 4 4.5 5 6 min 2.25 2.75 3.2 3.7 4.2 4.7 5.7 P Pitch(±10%) 1.1 1.35 1.6 1.8 2 2.2 2.6 A max 2.1 2.35 2.6 2.8 3 3.2 3.6 DK max=nominal size 5 6 7 8 9 10 12 min 4.7 5.7 6.64 7.64 8.64 9.64 11.57 K 1.4 1.8 2 2.35 2.55 2.85 3.35 DP max=nominal size 1.5 1.9 2.15 2.5 2.7 3 3.7 min 1.1 1.5 1.67 2.02 2.22 2.52 3.22 SOCKET NO. 1 1 2 2 2 2 3 M 2.51 3 4 4.4 4.8 5.3 6.6
PRODUCT DETAILS
PRODUCT ADVANTAGES
ADVANTAGES OF COUNTERSUNK CHIPBOARD SCREWS
1. Countersunk chipboard screws can be used when doing general DIY work with particleboard and other softer types of wood.
2. When driven with chipboard screws, the top material is threaded in place.
3. Great for attaching hinges to kitchen cabinets and doors, as galvanizing helps the screws blend in with the hinges.
4. On csk chipboard screws, the threads run all the way down the length of the screw to the underside of the head. This makes the screws especially useful in situations where a super-holding force is required.
5. AYA relies on advanced equipment and professionals to produce fiberboard nails to ensure quality.
QUALITY INSPECTION
1. The QC inspectors are well experienced in product knowledge as well as manufacturing techniques. Special instruments are applied to conduct multiple tests to ensure that the final products could meet the requirements of the market and customers.
2. Experienced QC staff can provide customers with accurate quality inspection reports.
3. Final product inspection is a key point. AYA has a complete sampling check system for this important task and each detail will be fully inspected.
PACKAGING & CONTAINER LOADING
1. Mature warehousing and logistics systems and digital tools make the goods delivery highly efficient.
2. Automated packing lines improve the quality and speed of the packaging work.
3. AYA has always attached great importance to the R&D of the packaging to improve the appearance as well as the durability in the process of shipment.
4. Packaging is important for product preservation as well as safety. AYA has constantly developed new solutions to keep products intact during the shipment process.
USAGE SCENARIOS
Contact AYA
