About this product
- Size: 7255*2280*2400
- Color: Red
- Power source: Other
- Automatic grade: Other
- Engine type: Diesel Engine
- Customized: Non-Customized
- Exports to: Middle East, EU, Other European Countries
About this product
- Size: 7255*2280*2400
- Color: Red
- Power source: Other
- Automatic grade: Other
- Engine type: Diesel Engine
- Customized: Non-Customized
- Exports to: Middle East, EU, Other European Countries
Product details
| Size | 7255*2280*2400 |
|---|---|
| Color | Red |
| Power source | Other |
| Automatic grade | Other |
| Engine type | Diesel Engine |
| Customized | Non-Customized |
| Walking mode | Wheeled |
Product details
| Size | 7255*2280*2400 |
|---|---|
| Color | Red |
| Power source | Other |
| Automatic grade | Other |
| Engine type | Diesel Engine |
| Customized | Non-Customized |
| Walking mode | Wheeled |
From the supplier
EAB18J
Self-propelled diesel articulated boom lift
Item
Unit
Performance Parameters
Max. working height
m
18
Max. platform height
m
16
Max. horizontal outreach radius
m
9.55
Span height
m
8.25
Lifting capacity
kg
230
Stowed Length
m
7.26
Width
m
2.28
Stowed Height
m
2.4
Wheelbase
m
2.4
Center ground clearance
m
0.4
Platform size (length*width)
m
1.83×0.76
Turning radius inside
m
1.87
Turning radius outside
m
4.8
Stowed drive speed
Km/h
4.2
Raised drive speed
Lm/h
0.8
Maximum grade ability
/
45%
Tire type
/
33×12-20
Turntable slewing speed
/
0～0.8
Turntable rotation
/
355°continuous
Platform leveling
/
Automatic leveling
Platform rotation
/
180°
Overall weight
kg
7800
System control voltage
V
12
Drive & steer mode
/
4×4×2
Engine
/
Yanmar/Kubota
Engine rated power
/
36kw/2400rpm
Fuel tank capacity
L
100
From the supplier
EAB18J
Self-propelled diesel articulated boom lift
Item
Unit
Performance Parameters
Max. working height
m
18
Max. platform height
m
16
Max. horizontal outreach radius
m
9.55
Span height
m
8.25
Lifting capacity
kg
230
Stowed Length
m
7.26
Width
m
2.28
Stowed Height
m
2.4
Wheelbase
m
2.4
Center ground clearance
m
0.4
Platform size (length*width)
m
1.83×0.76
Turning radius inside
m
1.87
Turning radius outside
m
4.8
Stowed drive speed
Km/h
4.2
Raised drive speed
Lm/h
0.8
Maximum grade ability
/
45%
Tire type
/
33×12-20
Turntable slewing speed
/
0～0.8
Turntable rotation
/
355°continuous
Platform leveling
/
Automatic leveling
Platform rotation
/
180°
Overall weight
kg
7800
System control voltage
V
12
Drive & steer mode
/
4×4×2
Engine
/
Yanmar/Kubota
Engine rated power
/
36kw/2400rpm
Fuel tank capacity
L
100
