About this product
- Materials: all aluminum
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: all aluminum
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | all aluminum |
|---|
Product details
| Materials | all aluminum |
|---|
From the supplier
Specification:
Can be customized
Usage:
Mainly used in three open door, multi doors and side by side etc High-end refrigerators, freezers.
Advantages:
1,adopting aluminium tube and fin,saving cost
2.Adopting Continuous tube and canted design
(1)Continuous tube decreases the number of joints and reduces the probability of leaking
(2)Canted design saves room, increases the density of aluminium tube and improves efficiency of
heat exchange
(3)Canted design improves air turbulence and efficiency of heat exchange
3.Improve the fin’s surface area and improves the efficiency of heat exchange
Raw material
(1)Normal Al tube:OD 8mm, wall thickness:0.7-1.2mm,and can be customized
(2)Al foil thickness: 0.14-0.17mm
Application
refrigeration parts
Structure
slant inserting type
Key process
prepare the material→starving tube and shaping→inserting fins and
enlarging tube→ leakage test→keeping pressure→packing
Performance
(1)With passivation surface treatment to prevent corrosion
(1)Inner cleanness can meet the requirement of R134a and CFC cooling system
(2) Can satisfy the cooling capability requirements of the designed refrigerator.
Residual moisture
≤20mg/m2
Residual impurity
≤30mg/m2
Residual mineral oil
≤7mg/m2
From the supplier
Specification:
Can be customized
Usage:
Mainly used in three open door, multi doors and side by side etc High-end refrigerators, freezers.
Advantages:
1,adopting aluminium tube and fin,saving cost
2.Adopting Continuous tube and canted design
(1)Continuous tube decreases the number of joints and reduces the probability of leaking
(2)Canted design saves room, increases the density of aluminium tube and improves efficiency of
heat exchange
(3)Canted design improves air turbulence and efficiency of heat exchange
3.Improve the fin’s surface area and improves the efficiency of heat exchange
Raw material
(1)Normal Al tube:OD 8mm, wall thickness:0.7-1.2mm,and can be customized
(2)Al foil thickness: 0.14-0.17mm
Application
refrigeration parts
Structure
slant inserting type
Key process
prepare the material→starving tube and shaping→inserting fins and
enlarging tube→ leakage test→keeping pressure→packing
Performance
(1)With passivation surface treatment to prevent corrosion
(1)Inner cleanness can meet the requirement of R134a and CFC cooling system
(2) Can satisfy the cooling capability requirements of the designed refrigerator.
Residual moisture
≤20mg/m2
Residual impurity
≤30mg/m2
Residual mineral oil
≤7mg/m2
