Fiberglass Mesh is woven by fiberglass yarns, then alkaline-resistant latex coated. It owns great alkaline-resistant and high strength. As a perfect engineering material in construction, It is widely used to reinforce cement, stone, wall materials, roofing, gypsum and so on.

Main characteristics:
1.Good chemical stability: Alkali-resistant, acid-resistant, waterproof,, cement erosion-resistant, and other chemicals' corrosion resistant; and strong resin bonding, soluble in styrene.
2.Outstanding craftsmanship include coating enough alkali-resist glue, our coating glue is produced by Germany BASF which can keep 60-80% strength after test in Naoh 28days later, so that guarantee high strength, high tensility, light weight.
3.Our fiberglass yarn is supplied by Jushi Group which is the largest producer of fiberglass yarn in the world like Saint Gobain, it's 20% extra strong strength and beauty surface than normal fiberglass yarn!
4.Strength retention rate> 90%, elongation
5.Good dimensional stability, stiffness, smoothness an difficult to shrink and deformation, good positioning property
6.Good impact resistance and not easy to be teared.
7.Fire resistant, thermal insulation, sound insulation, insulations etc.

Useage:
1.75g / m2 mesh fabric used in the reinforcement of thin slurry, to eliminate small cracks and scattered throughout the surface pressure.
2.110g / m2 mesh cloth is widely used in indoor and outdoor walls, prevent the various materials (such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion coefficient of wall crack and break
3. 145g/m2 mesh fabric used in the wall and be mixed in various materials (such as brick, light wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure, especially in the external wall insulation system (EIFS ).
4. 160g / m2 mesh fabric used in insulator layer of reinforcement in the mortar, through shrinkage and temperature changes by providing a space to maintain movement between the layers, prevent crack and rupture due to shrinkage or temperature change.

Fiberglass mesh Specification:

Item Number

Yarn(Tex)

Mesh(mm)

Density Count/25mm

Tensile Strength × 20cm

Woven Structure

Content of resin%

Warp

Weft

Warp

Weft

Warp

Weft

Warp

Weft

45g2.5x2.5

33×2

33

2.5

2.5

10

10

550

300

Leno

18

60g2.5x2.5

40×2

40

2.5

2.5

10

10

550

650

Leno

18

70g 5x5

45×2

200

5

5

5

5

550

850

Leno

18

80g 5x5

67×2

200

5

5

5

5

700

850

Leno

18

90g 5x5

67×2

250

5

5

5

5

700

1050

Leno

18

110g 5x5

100×2

250

5

5

5

5

800

1050

Leno

18

125g 5x5

134×2

250

5

5

5

5

1200

1300

Leno

18

135g 5x5

134×2

300

5

5

5

5

1300

1400

Leno

18

145g 5x5

134×2

360

5

5

5

5

1200

1300

Leno

18

150g 4x5

134×2

300

4

5

6

5

1300

1300

Leno

18

160g 5x5

134×2

400

5

5

5

5

1450

1600

Leno

18

160g 4x4

134×2

300

4

4

6

6

1550

1650

Leno

18

165g 4x5

134×2

350

4

5

6

5

1300

1300

Leno

18

1,What is your MOQ?
Our MOQ is usually 1x20ft container.But we accept lower quantity for your trial order. Please feel free to inform us your plan for purchasing, we will offer the price correspond to your qty. And we hope your would increase your order qty after you check our product quality and know our services.

2,What is the shipping port?
We ship the goods via Shanghai port.

3, How many colors are available?

We can do custom color when reach our MOQ qty.
Our regular colors are white, yellow, green, blue, orange, red etc

4,What format of the file do you need if I want to do my own design?

For printing label design, we need AI or PDF file for set up the print-plate.

5,What is your delivery time?
The time of delivery is about 10~15days after we receive the deposit.

 6,What is your sample time?
Usually we will take 7-10 days to make the samples.

 7,Which Shipment way is available?

By sea to your designated port.

8, Which Payment way is workable?

A: Irrevocable L/C, Cash, PayPal, Credit card and T/T money transfers.

B: 30% T/T deposit in advance, 70% balance before shipment after presentation of ready cargo.

C: L/C ( Irrevocable LC at sight)

If you need custom size such as gram weight and mesh size etc or private logo pls feel free inquiry us!
