Air Cooled Generator Set
HEBEI HOUFENG QIANYUAN NEW ENERGY TECHNOLOGY CO., LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
Air Cooled Generator Set
HEBEI HOUFENG QIANYUAN NEW ENERGY TECHNOLOGY CO., LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Free quotes from independent agents · supplier checks approx. $5–$100 · 100% refund if not satisfied
About this product
- Size: 1550*850*1200mm
- Color: blue
- Stroke: FourStrokes
- Output type: ACThreePhase
- Cooling method: WindCooling
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Size: 1550*850*1200mm
- Color: blue
- Stroke: FourStrokes
- Output type: ACThreePhase
- Cooling method: WindCooling
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Size | 1550*850*1200mm |
|---|---|
| Color | blue |
| Stroke | FourStrokes |
| Output type | ACThreePhase |
| Cooling method | WindCooling |
Product details
| Size | 1550*850*1200mm |
|---|---|
| Color | blue |
| Stroke | FourStrokes |
| Output type | ACThreePhase |
| Cooling method | WindCooling |
From the supplier
air cooled engine deutz models: F2L912, F3L912, F4L912, F4L912T, F6L912, F6L912T, BF6L913, BF6L913C
Alternator brand : stamford , Leroy Somer, Leroy Some,Marathon .
Generator set power: 12kw 15kva, 20kw 25kva, 24kw 30kva, 36kw 45kva, 40kw 50kva, 52kw 65kva, 75kw 93.75kva, 100kw 125kva
Technical Data:Model
HF20D
Genset
Prime power(kw/kva) when 50HZ
20/25
Engine
Model
F3L912
Prime power
24KW/1500rpm
Number of cylinder
3
Cylinder arrangement
vertical line
Cooling system
Air cooled
Aspiration
Naturally
Governor
Mechanical
Bore*Stroke
100*120mm
50% Fuel consumption
3.24L/hr
75% Fuel consumption
4.67L/hr
100% Fuel consumption
6.06L/hr
Alternator
Excitation type
Brushless excitation
Rated current(A)
38
Insulative grade
H
Protection grade
IP22
Voltage
220/380V
Tolerance of voltage
≤±1%
Dimension
1550*850*1200mm
Weight
610
From the supplier
air cooled engine deutz models: F2L912, F3L912, F4L912, F4L912T, F6L912, F6L912T, BF6L913, BF6L913C
Alternator brand : stamford , Leroy Somer, Leroy Some,Marathon .
Generator set power: 12kw 15kva, 20kw 25kva, 24kw 30kva, 36kw 45kva, 40kw 50kva, 52kw 65kva, 75kw 93.75kva, 100kw 125kva
Technical Data:Model
HF20D
Genset
Prime power(kw/kva) when 50HZ
20/25
Engine
Model
F3L912
Prime power
24KW/1500rpm
Number of cylinder
3
Cylinder arrangement
vertical line
Cooling system
Air cooled
Aspiration
Naturally
Governor
Mechanical
Bore*Stroke
100*120mm
50% Fuel consumption
3.24L/hr
75% Fuel consumption
4.67L/hr
100% Fuel consumption
6.06L/hr
Alternator
Excitation type
Brushless excitation
Rated current(A)
38
Insulative grade
H
Protection grade
IP22
Voltage
220/380V
Tolerance of voltage
≤±1%
Dimension
1550*850*1200mm
Weight
610
About the supplier
Main products: Diesel Engines, Power-generating Sets, Diesel engine, V Engine, Other Engine
- ✓Exhibited at 2 recent Canton Fairs
- ✓Foreign Trade Company
- ✓Founded 2010
Manufacturing exhibitors show in Phase 1 of the Canton Fair, 15 to 19 October 2026.
- Exhibited at 2 recent Canton Fairs
- Foreign Trade Company
- Founded 2010
